  11. Duplex Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded
Hubbell Wiring Device-Kellems Duplex Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded HBL8200SGA - main

Duplex Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded

  • Mfr # HBL8200SGA

  • Zoro # G2979663

product price: $46.65
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
HBL8200SGA
Zoro #
G2979663
UPC #
783585152226
Country of Origin
China

Dimensions

Dimensions
3.29 in x 1.65 in x 1.27 in
Wire Size
#12 AWG to #10 AWG
Display Size
Standard Sized Product
Maximum Wire Size
10 AWG
Mount Hole Center-to-Center Height
3.3 in
Face Plate Height
2.8 in
Overall Depth
1.3 in
Face Plate Width
1.6 in
Minimum Wire Size
12 AWG

Details

Item
Duplex Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Grounded
Housing Color
Brown
Mount Type
Flush
IP Rating
IP20
Standards
CSA Certified C22.2 No. 42 File 285, Federal Specification W-C-596, NEMA WD-6, UL 498 File E2186
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Color
Brown
Ligature Resistant
Yes
Voltage
125VAC
Outlet Type
Duplex
Mounting Type - Plugs and Receptacles
Flush
Outlet Type - Plugs and Receptacles
Standard Duplex
HP
1/2 hp
Weather Resistant
No
Number of Gangs
1
Mounting Type
Flush
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Power Indicator
No
Sub-Category
Duplex Receptacles
Material
Thermoplastic
NEMA Configuration
5-15
Weather Resistant - Plugs and Receptacles
No
Application Environment
Heavy Use Hospital Grade
Surge Suppression
No
Wiring Method - Plugs and Receptacles
Wire Lead
Corrosion Resistant
No
Tamper Resistant
Yes
Application
Extra Heavy Duty Hospital Grade
Connectivity
Wire Leads
Carton Quantity
10
Number Of Wires
3-Wire
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Environmental Rating
Indoor Dry Unless Protected By Additional Means
Brand
Hubbell Wiring Device-Kellems
Mounting Hardware Material
Screw Mounting
Style
Tamper Resistant
Wattage
1875 W
Dielectric Strength
Withstands 2,000V minimum
Series
Hospital Grade
Type
Receptacle
Nema Rating
5-15R
Maximum Horsepower
0.5
Amperage
15 A
Grade
Hospital Grade Fed. Spec.
Includes
Grounding Clip, Mounting Hardware, Wall Plate or Weatherproof Cover
Housing Material
Thermoplastic
Polarized
Yes
AFCI
No
Connection Orientation
Straight
Contact Material
Nickel-Plated Brass
GFCI
No
Horsepower Rating
1/2 hp
UL 94 Flammability Rating
5VA, V-0
Cover Type
No Cover
Includes Mounting Hardware
Yes
Minimum Operating Temperature
-40 Degrees F
Surge Protection
No
NEMA Enclosure Rating
1
Shrouded
No
For Location
Indoor
Maximum Operating Temperature
167 Degrees F
IP Suitability
IP20
Device Grade
Heavy Duty Spec Grade
Dielectric Voltage
Withstands 2,000V minimum
Poles and Wires
2 Pole, 3 Wire
Ground Terminal Accommodation
#12-#10 AWG stranded or solid copper wire only
Flammability
UL 94V-0 and UL 94-5 VA
Device Color
Brown
Current Interrupting
Certified for current interrupting at full rated current
Terminal Identification
Terminals identified in accordance with UL 498 and CSA
Operating Temperatures
Maximum continuous 75°C; minimum -40°C (w/o impact)

Description

The HUBBELL 15A Duplex Receptacle 125VAC 5-15R BN is a duplex receptacle rated for 15A and 125VAC. It features tamper-resistant construction and is rated for use at 15 amps and 125 volts AC. The unit includes integral wire leads for fast installation, nickel-plated brass contacts, and a four-point grounding system to provide redundant ground continuity.


Key Features of the HUBBELL 15A Duplex Receptacle:

  • Amperage/Voltage: Rated for 15 A, 125 VAC operation

  • NEMA Configuration: NEMA 5-15R duplex outlet

  • Contact Material: Nickel-plated brass contacts

  • Tamper Resistant: Tamper-resistant mechanism

  • Grounding System: Four-point grounding system

  • Wire Connection Type: Integral wire leads with screw terminals support back or side wiring methods

  • Mounting Type: Flush mount with included mounting hardware; standard size device suitable for single gang installations

  • Housing Material & Flammability Rating: Thermoplastic housing meets UL94V-0 and UL94-5VA flammability standards

  • Operating Temperature Range: -40°C minimum (without impact) to +75°C maximum continuous use; withstands up to 167°F (75°C)

  • Certifications & Standards: CSA Certified C22.2 No.42 File 285, Federal Specification W-C-596, NEMA WD-6, UL498 File E2186 compliant
