  6. Flanged Locking Inlet, 15 A, 125V AC, Single Phase, 2 Pole, Screw Terminals, Black
Hubbell Wiring Device-Kellems Flanged Locking Inlet, 15 A, 125V AC, Single Phase, 2 Pole, Screw Terminals, Black HBL7466 - main

Flanged Locking Inlet, 15 A, 125V AC, Single Phase, 2 Pole, Screw Terminals, Black

  • Mfr # HBL7466

  • Zoro # G000702505

product price:  $28.39
/ea

Key Features

NEMA Receptacle Configuration
ML-1P
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
HBL7466
Zoro #
G000702505
UPC #
783585237312
Country of Origin
United States

Dimensions

Wire Size
15A #14 AWG
Length
1.63 in
Dimensions
1.63 in x 1.63 in x 0.94 in
Height
0.94 in
Width
1.63 in

Details

Item
Locking Plug
NEMA Receptacle Configuration
ML-1P
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
2
Wire Connection Type
Screw Terminals
Grounding
Non-Grounded
Housing Color
Black
Cover Type
No Cover
Flange Type
Flanged
Standards
Certified to CSA C22.2 No.42, Listed to UL 498
Resistance Properties
Moisture Resistant
Flange Material
.025" Stainless Steel
Material
zinc plated
IP Rating
IP20
Wiring Style
Standard
Special Features
Molded In or Stamped On
Application
Heavy Duty Industrial
Flammability
HB or better per UL94/CSA 22.2 No.0.17
Lock Type
Twist-lock
Terminal Designations
Terminals identified in accordance with UL 498 (X, Y, Z, White, Green)
Insulation
Insulated Body
OEM Brand Name
Hubbell Wiring Device-Kellems
Material - Mounting Hardware
Screw Mounting
Dielectric Strength
Withstands 2,000V minimum
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - HB or better per UL94/CSA 22.2 No.0.17 Environmental - Moisture Resistance - IP20 Suitability Environmental - Operating Temperatures - Maximum Continuous 75°C, Minimum -40°C (w/o impact) Mechanical - Terminal Accommodation - #18 AWG - #14 AWG solid or stranded copper wire only. Mechanical - Terminal Identification - Terminals identified in accordance with UL 498
Temperature Rating
Maximum Continuous: 75° C; Minimum Continuous: -40° C w/o impact, -25° with impact.
Amperage Rating
15 A

Description

Hubbell Wiring Device Kellems, Locking Devices, Midget TwistLock,Industrial, Flanged Inlet, 15A 125V, 2-Pole 2-Wire Non Grounding, ML-1P,Screw Terminal, Steel, Non-Polarized
