Shop HUBBELL WIRING DEVICE-KELLEMS

Liquid Tight Connector, 1in, Straight, Gray

  • Mfr # SHC1043CR

  • Zoro # G2850425

product price:
$
12.49
/ea

Key Features

Material
Nylon
Box Connection
1 in MNPT
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Color
Gray
Material - Cord Connector
Nylon
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
SHC1043CR
Zoro #
G2850425
UPC #
783585208152
Country of Origin
United States

Dimensions

Length - External Strain Relief
No External Strain Relief
Length - Box to End of Connector
1 3/4 in
Length
2-29/64"
Cord Dia. Range
0.88 in to 1.00 in
Conduit Size
1"
Hub Size
1 in
Overall Length
2 1/2 in
Form Size
F4
Thread Size
1 in
Compatible Conduit Trade Size
1 in
Dimension E A/C
1.84" (46.7)
Dimension E A/F
1.63" (41.4)
Dimension A
1.88" (47.8) Dia.
Recommended Knockout Hole Size
1.36"- 1.41" (34.5-35.7)
Dimension B
1.75" (44.4) Ref.
Cord Diameter Range
.88"- 1.00" (22.2- 25.4)
Dimension C
.70" (17.8)
Dimension D
1.01" (25.7) Throat Dia.
Height
2.45 in
Display Size
1" NPT
Dimensions
1.88 in x 1.88 in x 2.45 in
Width
1.88 in
Wire Rope Length
2 1/2 in

Details

Item
Liquid Tight Cord Connector
Material
Nylon
Box Connection
1 in MNPT
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Color
Gray
Material - Cord Connector
Nylon
Gland Color Code
Gray
Strain Relief Type
No External Strain Relief
Style - Connector
Straight
Material - External Strain Relief
No External Strain Relief
Insulated
Yes
Standards
CSA LR27378, UL E54218(M)
Connector Type
Straight
Body Color - Cord Connector
Gray
Item - Cord Connector
Liquid Tight Cord Connector
Number of Cords
1
For Use With
Kellems Wire Management
Thread Gender
Male
Collar Material
Nylon
Resistance Properties
Corrosion Resistant
Bushing Material
Neoprene
Connection Orientation
Straight
Thread Type
NPT
NEMA Rating
NEMA 12, NEMA 13, NEMA 4, NEMA 4X
Body Color
Gray
Minimum Operating Temperature
-30 Degrees F
Liquid Tight
Yes
Environmental Rating
Not Flammable, Hazardous Locations
For Minimum Cable OD
0.88 in
IP Rating
IP66
Body Material
Nylon
For Maximum Cable OD
1 in
Maximum Operating Temperature
225 Degrees F
Grommet Color Code
Gray
Compatible Conduit Type
Liquid Tight Cord Connector
Effective Operating Temperature
-30°F to +225°F (-34°C to +107°C)
Material/Style
Nylon Standard Style
Hazardous Locations
Hubbell cord connectors are suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2 N.E.C. Reference 501-4(b), 502-4(a), 502-4(b), 503-3(a), and 503-3(b)., Used in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class Ill Div. 1 & 2 in accordance with the NEC
Operating Temperatures
-30°F to +225°F (-34°C to +107°C)
Product Type
Cord Connectors
Certifications
UL Listed in accordance with Standard 514B, CSA Certified, United States Coast Guard Approval, Title 46-Part 111.
Cord Connector Body Style
Straight Male
Flammability
UL 94-V2, Hubbell nylon cord connectors have a UL 94-V2 rating.
Color Code
Gray
Application
Straight Male- Form 4
Number Of Conductors
Single
Industry Standard(s)
UL Listed
Temperature Rating
Minimum -30 Deg F to 225 Deg F (-34 Deg C to 107 Deg C)
Type
Straight Male
Series
Standard Duty
Item Type
Cord Connectors
Material - Mounting Hardware
Locknut or Tapped Opening
Conductor Range
0.88-1 in (22.2-25.4 mm)
Environmental Conditions
Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting.
Performance
Environmental - Flammability - UL 94-V2 Environmental - Hazardous Locations - Used in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class Ill Div. 1 & 2 in accordance with the NEC Environmental - Operating Temperatures - -30°F to +225°F (-34°C to +107°C)
OEM Brand Name
Hubbell Wiring Device-Kellems

Description

Liquid Tight Cord Connector, Cord Dia. Range 0.88 in to 1.00 in, Box Connection 1 in MNPT, Material - Cord Connector Nylon, External Strain Relief Material No External Strain Relief, Gland Color Code Gray, Body Color - Cord Connector Gray, Number of Cords 1, Style - Connector Straight, Strain Relief Type No External Strain Relief, External Strain Relief Length No External Strain Relief, Length - Box to End of Connector 1 3/4 in, Insulated Yes, Standards CSA LR27378, UL E54218(M)
