  11. Locking Connector, 30 A, 250V AC, Single Phase, 2 Pole, Screw Terminals, Gray
Hubbell Wiring Device-Kellems Locking Connector, 30 A, 250V AC, Single Phase, 2 Pole, Screw Terminals, Gray HBL2621F - main

Locking Connector, 30 A, 250V AC, Single Phase, 2 Pole, Screw Terminals, Gray

  • Mfr # HBL2621F

  • Zoro # G000701089

product price: $46.51
/ea

Key Features

Current Rating
30 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
Number of Wires
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL2621F
Zoro #
G000701089
UPC #
783585038858
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
0.9375 in
For Minimum Cable Diameter
0.36 in
Dimensions
2.75 in x 2.26 in x 2.26 in
Width
2.26 in
Length
2.75 in
Height
2.26 in
Wire Size
#16 AWG to #8 AWG

Details

Item
Locking Plug
Current Rating
30 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
Number of Wires
2
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Shrouded
No
Grounding
Grounded
Housing Color
Gray
Cap Type
No Cap
IP Rating
IP20
Standards
CSA C22.2 No.42, UL 498
Resistance Properties
Heat Stabilized
Body Material
Gray nylon
Material
Natural White Nylon
Special Features
Terminals identified in accordance with UL 498 (X, Y, Z, White, Green)
Application
Extra Heavy Duty Industrial
Flame Resistant
HB or better per UL 94 or CSA 22.2 No. 0.6
Weight
0.35
Dielectric Strength
2,000V minimum
Cord Range
0.360"-0.930" (9-24)
Cord Type
All Listed Portables
Performance
Electrical-Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Mechanical - Terminal Accommodation - #16 AWG - #8 AWG stranded copper wire only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 Environmental - Flammability - HB or better per UL94/CSA 22.2 No.0.17 Environmental - Moisture Resistance - IP20 Suitability Environmental - Operating Temperatures - Maximum Continuous 75°C Minimum -40°C (w/o impact)
Material - Mounting Hardware
Cord Mounted
OEM Brand Name
Hubbell Wiring Device-Kellems
NEMA Receptacle Configuration
L6-30P

Description

Hubbell Wiring Device Kellems, Locking Devices, TwistLock, Industrial,Male Plug, 30A 250V, 2-Pole 3-Wire Grounding, L6-30P, Screw Terminal,Gray, High Temp Version,
