Hubbell Wiring Device-Kellems Pin And Sleeve, Interlock, 60A, UnFused HBL460MIS2W - main

Pin And Sleeve, Interlock, 60A, UnFused

  • Mfr # HBL460MIS2W

  • Zoro # G3181771

product price: $1,890.00
/ea
Free Shipping & Returns

Key Features

Type
Pin And Sleeve, Insulgrip, Unfused
Voltage
600V AC/250V DC
Amps
60 A
Hub
1 1/4 in
Number of Poles
3
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL460MIS2W
Zoro #
G3181771
UPC #
783585514895
Country of Origin
Poland

Dimensions

Maximum Wire Size
2 AWG
Overall Width
10.18 in
Hub Diameter
1 in
Minimum Wire Size
8 AWG
Overall Height
15.36 in

Details

Item
Mechanical Interlock Device
Type
Pin And Sleeve, Insulgrip, Unfused
Voltage
600V AC/250V DC
Amps
60 A
Hub
1 1/4 in
Number of Poles
3
Phase
Single, Three
Number of Wires
4
Viewing Window
No
Fused / Nonfused
Nonfused
Accepts Plug Number
5HJ29
Includes
Mounting Feet
Use With
5HJ29
HP
50 hp
Standards
cULus
Color
gray
IP Rating
IP66
Maximum Operating Temperature
167 Degrees F
Circuit Breaker Amp Rating
60 A
Minimum Operating Temperature
-40 Degrees F
Circuit Breaker
No
UL 94 Flammability Rating
5VA, V-0
Grounding
Grounded
Electrical Connection Type
Pin and Sleeve
Voltage Rating
600V AC/250V DC
Reverse Service
No
NEMA Enclosure Rating
Not Rated
Resistance Properties
Watertight
Locking Handle
Yes
Compatible Plug Manufacturer Part Number
5HJ29
Includes Mounting Hardware
Yes
Housing Material
Thermoplastic
Current Rating
60 A
Fuse Protection
Non-Fused
Contact Material
Brass
Horsepower Rating
50 hp
Conduit Hub
Zinc, Watertight
Terminal Accommodations
#2 To #10 AWG copper wire only
Certification
UL Listed, CSA Certified
Max Working Voltage
600V AC RMS
Shaft
VALOX
Poles and Wires
3 Pole, 4 Wire
Current Interrupting
Certified for current interrupting at full rated current.
Dielectric Withstand Voltage
Withstands 3,000V AC
Certifications
UL Listed, CSA Certified.
Base
VALOX
Ingress Protection
IP66 Suitability
Service Style
Standard
Endurance
Mechanical: 10,000 cycles
Enclosure Hinge Pins
Nickel Plated Brass
Amperage
60A
Fuse Types
UL Listed Class "J", CSA Certified HRCI-J
Short Circuit Withstand
Suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical amperes at the voltage rating of the receptacle.
Flammability
UL94-5VA and V-0 classification.
Terminal Identification
Terminals identified in accordance with North American and International conventions.
Mechanical Interlock Items
Complete Unit
Gaskets
Neoprene
Enclosure Inserts
Brass
UV Resistance
All materials are UV Stabilized.
Hinge Spring
Stainless Steel (300 series)
Mechanical Interlock Device Standard
Insulgrip
Assembly Screws
Stainless Steel (300 series)
Handle
Valox
Moisture Resistance
Outdoor: 4X (Watertight, Washdown) Indoor: Type 12 (Dusttight, Falling Dirt and Non-Corrosive Liquids).
Operating Temperatures
Maximum Continuous: 60° C; Minimum Continuous: -40° C w/o impact.
Shaft Seal
Neoprene
Impact Resistance
In accordance with UL746C

Description

The HUBBELL Pin And Sleeve Mechanical Interlock Device, 60A, Unfused is a non-metallic unit that combines a disconnect switch with a pin and sleeve receptacle. This device features an interlock mechanism that restricts plug removal when the switch is in the ON position.


Key Features of the HUBBELL Pin And Sleeve Mechanical Interlock Device:

  • Amperage/Voltage: Rated for 60A at up to 600V AC or 250V DC

  • Electrical Connection: Pin and sleeve type; accepts compatible plug number 5HJ29

  • Poles/Wires/Phase: For use in single- or three-phase applications; features 3 poles, 4 wires

  • Enclosure & Resistance: Thermoplastic housing with stainless steel hardware; IP66 ingress protection; UV stabilized materials

  • Operating Temperature Range: -40°C minimum to +75°C maximum continuous temperature

  • Circuit Protection: Listed as current interrupting at full rated current per certification standards

  • Lockout Capability: High-visibility red handle can be locked in OFF position per OSHA lockout/tagout requirements; enclosure door also lockable

  • Cable Accommodation: Terminal accommodations for #2 to #10 AWG copper wire only

  • Certifications & Standards: UL Listed, CSA Certified, cULus compliant; meets Insulgrip mechanical interlock standard

The enclosure is constructed from thermoplastic VALOX material and rated IP66 for use in indoor (Type 12) or outdoor (Type 4X) environments requiring dust-tightness and watertightness.
