  6. Pin & Sleeve Receptacle, 60 A, 600V AC, Single Phase, 3 Pole, Style 1 Grounding, NEMA 3, 4, 4X
Hubbell Wiring Device-Kellems Pin & Sleeve Receptacle, 60 A, 600V AC, Single Phase, 3 Pole, Style 1 Grounding, NEMA 3, 4, 4X HBL460RS1WR - main

Pin & Sleeve Receptacle, 60 A, 600V AC, Single Phase, 3 Pole, Style 1 Grounding, NEMA 3, 4, 4X

  • Mfr # HBL460RS1WR

  • Zoro # G000701669

product price:  $402.99
/ea
Free Shipping & Returns

Key Features

Voltage Rating
600V AC
Phase
Single
Number of Poles
3
Number of Wires
4
IP Rating
Not Rated
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
HBL460RS1WR
Zoro #
G000701669
UPC #
783585012445
Country of Origin
United States

Dimensions

Wire Size
6 to 4 AWG
Display Size
Standard Sized Product

Details

Item
Pin & Sleeve Receptacle
Current Rating
60 A
Voltage Rating
600V AC
Phase
Single
Number of Poles
3
Number of Wires
4
IP Rating
Not Rated
NEMA Enclosure Rating
3, 4, 4X
Wire Connection Type
Screw Terminals
Housing Color
Black, Gray
Cap Type
No Cap or Cover
Standards
CSA Certified/CSA Spec. C22.2 No. 182.1, UL Listed and CSA Certified Type 4X, UL Standard 1682
Resistance Properties
Watertight
Material
Thermoplastic
Body Material
Epoxy Painted Aluminum
Grounding Style
Style 1
Application
Metallic with Nylon Shroud
Operating Temp. Range
-40° C to 75° C
Series
UL 1686 Class 1 Insulgrip®
OEM Brand Name
Hubbell Wiring Device-Kellems
Wattage
36000
Environmental Conditions
Watertight
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 3,000V AC Electrical - Max. Working Voltage - 600V AC RMS Environmental - Flammability (Enclosure) - UL 94V-0 and CSA C22.2 No. 0.17 Environmental - Moisture Resistance - Type 3, 4, 4X per UL 50E and CSA 22.2, No. 94 Environmental - Operating Temperatures - Max. Continuous 75°C Min. -40°C w/o impact -25° with impact Mechanical - Impact Resistance - Per CSA C22.2, No. 182.1, UL 1682 Mechanical - Product Identification - Identification and ratings are permanently fastened to the device housing Mechanical - Terminal Identification - Terminals identified in accordance with UL 1686(1, 2, 3, Green)
Material - Mounting Hardware
Screw Mounting
Industry Standard(s)
CSA Certified to CSA Spec. C22.2 No. 182.1 UL Listed and CSA Certified Type 4X UL Standard 1682
Style
Reversed Service,Style 1 Grounding
Flange Type
Flanged

Description

Hubbell Wiring Device Kellems, Heavy Duty Products, Insulgrip Pin andSleeve Devices, Industrial Grade, Female, Receptacle, 60A 600V AC, 3-Pole 4-Wire Grounding Style 1, Terminal Screws, Gray andBlack,Watertight- Reversed Service
