  6. Straight Blade Connector, 7-15R, 15 A, 277V AC, 2 Pole, 3 Wire, Screw Terminals, Brown
Hubbell Wiring Device-Kellems Straight Blade Connector, 7-15R, 15 A, 277V AC, 2 Pole, 3 Wire, Screw Terminals, Brown HBL5324 - main

Straight Blade Connector, 7-15R, 15 A, 277V AC, 2 Pole, 3 Wire, Screw Terminals, Brown

  • Mfr # HBL5324

  • Zoro # G1484165

product price:  $50.89
/ea

Key Features

NEMA Receptacle Configuration
7-15R
Current Rating
15 A
Voltage Rating
277V AC
Phase
Single
Number of Poles
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL5324
Zoro #
G1484165
UPC #
783585013374
Country of Origin
United States

Dimensions

Cord Size
0.296 in to 0.625 in
For Maximum Cable Diameter
0.63 in
For Minimum Cable Diameter
0.30 in
Minimum Wire Size
14 AWG
Maximum Wire Size
10 AWG
Display Size
Standard
Wire Size
#14 AWG to #10 AWG

Details

Item
Straight Blade Connector
NEMA Receptacle Configuration
7-15R
Current Rating
15 A
Voltage Rating
277V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Shrouded
No
Grounding
Grounded
Housing Color
Brown
Cap Type
No Cap or Cover
Maximum Operating Temperature
75 Degrees C
Minimum Operating Temperature
-40 Degrees C
IP Rating
IP20
Standards
CSA Certified, NEMA WD-6, UL Listed
Resistance Properties
Corrosion Resistant
Material
Nylon
Voltage
277VAC
Antimicrobial
No
Power Indicator
No
HP
2 hp
Grade
General
Corrosion Resistant
No
Special Features
Insulated Body
Housing Material
Thermoplastic Elastomer
Market
Commercial, Industrial
Polarized
Yes
Power Indicating Light
No
Contact Material
Brass
For Location
Indoor
For Environment
Dry
Horsepower Rating
2 hp
Weight
0.2 lb
Dielectric Strength
Withstands 2,000V minimum.
Grade - Plugs and Receptacles
General
NEMA Plug Configuration - Plugs and Receptacles
7-15R
Application
Industrial/Commercial
Material - Mounting Hardware
Cord Mounted
Number Of Conductors
3-Wire Grounding
Nema Rating
7-15R
Industry Standard(s)
CSA Certified to C22.2 No. 42 File 280C NEMA® WD-6 Compliant UL Listed to UL498 File E1706
Insulation
Insulated Body
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 V-1 or better Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #14-#10 AWG stranded copper wire only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Horsepower - Maximum
2
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Temperature Rating
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Conductor Range
#14 AWG to #12 AWG
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
OEM Brand Name
Hubbell Wiring Device-Kellems
Cord Range
0.296"-0.625" (7.5-15.9)

Description

Straight Blade Connector, Connection Orientation Straight, Current Rating 15 A, Housing Color Brown, NEMA Receptacle Configuration 7-15R, Number of Poles 2, Number of Wires 3, Phase Single, Resistance Properties Corrosion Resistant, Voltage Rating 277V AC, Wire Connection Type Screw Terminals, Cap Type No Cap or Cover, For Maximum Cable Diameter 0.63 in, For Minimum Cable Diameter 0.3 in, Grade General, Grounding Grounded, Horsepower Rating 2 hp, Housing Material Thermoplastic Elastomer
