  11. Straight Blade Plug, 14-20P, 20 A, 125/250V AC, 3 Pole, Screw Terminals, Grounded
Hubbell Wiring Device-Kellems Straight Blade Plug, 14-20P, 20 A, 125/250V AC, 3 Pole, Screw Terminals, Grounded HBL8411C - main

Straight Blade Plug, 14-20P, 20 A, 125/250V AC, 3 Pole, Screw Terminals, Grounded

  • Mfr # HBL8411C

  • Zoro # G2107892

product price: $67.97
/ea

Key Features

NEMA Plug Configuration
14-20P
Current Rating
20 A
Phase
Single
Number of Poles
3
Number of Blades
4
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL8411C
Zoro #
G2107892
UPC #
783585013114
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
0.775 in
For Minimum Cable Diameter
0.39 in
Cord Size
0.390 in to 0.775 in
Body Length
3.64 in

Details

Item
Straight Blade Plug
NEMA Plug Configuration
14-20P
Current Rating
20 A
Voltage Rating
125/250V AC
Phase
Single
Number of Poles
3
Number of Blades
4
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Angled
Grounding
Grounded
Housing Color
Black, White
IP Rating
IP20
Standards
CSA, UL
Resistance Properties
Corrosion Resistant
Antimicrobial
No
Special Features
Corrosion resistant
NEMA Configuration
14-20
Phase - Plugs and Receptacles
3
Material
Nylon
Corrosion Resistant
Yes
Number of Wires
4
NEMA Plug Configuration - Plugs and Receptacles
14-20P
Grade
Industrial
Grade - Plugs and Receptacles
Industrial
Voltage
125/250VAC
HP
1.0 Line to Neutral, 2.0 Line to Line
NEMA Rating
WD-6; 14-20P
Polarized
Yes
Insulation Material
Nylon
Market
Industrial
Horsepower Rating
1 hp, 2 hp
Housing Material
Nylon
Ground Screw Material
Plated Steel
Contact Blades Material
.075" Brass
Retainer Material
Polycarbonate
Environment
Dry
Temp. Rise
Max 30C after 250 cycles OL at 200 percent rated current
Terminal Screw Material
Brass
Body Material
Impact Modified Nylon
Ground Contact Blade Material
.075" Brass
Operating Temp.
-40°C to 60°C; Maximum continuous 75°C; minimum -40°C (w/o impact)
Body Style
Angle
Flammability
Rated HB or better UL94
Blade Holder Material
Nylon
Blade Material
Solid Brass
Dielectric Strength
Withstands 2000V per UL498
Weight (Lbs.)
0.4
Cord Clamp Material
Nylon

Description

Straight Blade Plug, Connection Orientation Angled, Current Rating 20 A, Grounding Grounded, Horsepower Rating 1 hp, 2 hp, Housing Color Black, White, IP Rating IP20, NEMA Plug Configuration 14-20P, Number of Blades 4, Number of Poles 3, Phase Single, Polarized Yes, Resistance Properties Corrosion Resistant, Voltage Rating 125/250V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, For Maximum Cable Diameter 0.775 in, For Minimum Cable Diameter 0.39 in, Grade Industrial
