Shop HUBBELL WIRING DEVICE-KELLEMS

Straight Blade Plug, 5-15P, 15 A, 250V AC, 2 Pole, Screw Terminals, Grounded

  • Mfr # HBL5266CAT

  • Zoro # G400702556

product price:
$
27.99
/ea

Key Features

NEMA Plug Configuration
5-15P
Current Rating
15 A,125V
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
HBL5266CAT
Zoro #
G400702556
UPC #
783585173108
Country of Origin
United States

Dimensions

Cord Size
.325"-.655" (8.3-16.6)

Details

Item
Straight Blade Plug
NEMA Plug Configuration
5-15P
Current Rating
15 A,125V
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Angled
Grounding
Grounded
Housing Color
Black
IP Rating
IP20
Standards
CSA C22.2, UL 498
HP
0.5 hp
Number of Wires
3
Special Features
Certified for current interrupting at full rated current.
Retainer Material
Polycarbonate-Clear
Blade Material
Solid Brass
Operating Temp.
-40°C to 60°C; Maximum continuous 75°C, minimum -40°C (w/o impact).
Terminal Screw Material
#8-32 Brass /Ni plated for neutral
Ground Screw Material
#8-32 Brass, Multiple Drive (Green)
Weight (Lbs.)
0.15
Flammability
Rated HB or better UL94
Cord Clamp Material
Nylon-Natural
Contact Blades Material
.060" (1.5) Brass
Body Style
Angle
Environment
Dry
Dielectric Strength
Withstands 2000V per UL498
Ground Contact Blade Material
.040" (1.0) Copper Alloy
Body Material
Impact Modified Nylon
Temp. Rise
Max 30C after 250 cycles OL at 200 percent rated current
Blade Holder Material
Nylon-Natural
Housing Material
Nylon-Black

Description

Hubbell Wiring Device Kellems, Straight Blade Devices, Male Plug,Insulgrip Heavy Duty, Industrial/Commercial Grade, Angled, 2-Pole 3-WireGrounding, 15A 125V, 5-15P, Clear, Single Pack
