  11. Straight Blade Plug, 5-20P, 20 A, 125V, 2 Pole, Screw Terminals, Grounded
Hubbell Wiring Device-Kellems Straight Blade Plug, 5-20P, 20 A, 125V, 2 Pole, Screw Terminals, Grounded HBL8315CAT - main

Straight Blade Plug, 5-20P, 20 A, 125V, 2 Pole, Screw Terminals, Grounded

  • Mfr # HBL8315CAT

  • Zoro # G3273812

product price: $33.89
/ea

Key Features

NEMA Plug Configuration
5-20P
Voltage Rating
125V
Phase
Single
Number of Poles
2
Number of Blades
3
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL8315CAT
Zoro #
G3273812
UPC #
783585180007
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
0.655 in
For Minimum Cable Diameter
0.25 in
Cord Size
0.250 in to 0.660 in
Wire Size
#18 AWG to #10 AWG
Cord Dia. Range
0.250-0.655 (6.4-16.6)
Maximum Wire Size
10 AWG
Minimum Wire Size
18 AWG
Height
2.11 in
Thickness
1.22
Width
1.53 in

Details

Item
Straight Blade Plug
NEMA Plug Configuration
5-20P
Current Rating
20 A
Voltage Rating
125V
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Angled
Grounding
Grounded
Housing Color
Clear
IP Rating
IP20
Standards
CSA C22.2, UL 498
Resistance Properties
Corrosion Resistant
Corrosion Resistant
Yes
Antimicrobial
No
NEMA Plug Configuration - Plugs and Receptacles
5-20P
Grade - Plugs and Receptacles
Hospital
Phase - Plugs and Receptacles
1
Voltage
125VAC
Number of Wires
3
Special Features
Corrosion resistant
Material
polycarbonate
HP
1.0
Grade
Hospital Grade
Color
Transparent
Type
Plug
Carton Quantity
10
Series
Hospital Grade
Maximum Horsepower
1
Amperage
20 A
Brand
Hubbell Wiring Device-Kellems
Nema Rating
5-20P
Dielectric Strength
Withstands 2,000V minimum
Style
Insulgrip
Number Of Wires
3-Wire
Polarized
Yes
Minimum Operating Temperature
-40 Degrees F
Maximum Operating Temperature
167 Degrees F
UL 94 Flammability Rating
HB
Insulation Material
Polycarbonate
Horsepower Rating
1 hp
Housing Material
Polycarbonate
Housing Material Finish
Nickel Plated
Weight (Lbs.)
0.15
Operating Temp.
Maximum continuous 75°C; minimum -40°C (w/o impact)
Body Style
Angled
Connector Type
Insulgrip
Flammability
UL 94 HB or better
Industry Standard(s)
Certified to CSA, C22.2, No. 42 File 285 Fed. Spec. W-C-596 UL Listed to UL498 File E1706
Horsepower - Maximum
1
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2000V AC minimum Environmental - Flammability - UL 94 HB or better Environmental - IP Suitability - IP20 Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #18-10 AWG Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Cord Range
0.250"-0.655" (6.4-16.6)
OEM Brand Name
Hubbell Wiring Device-Kellems
Application
Hospital Grade
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact

Description

• Individual wiring terminals completely enclosed
• Powerful, offsetting cord grips clamp on individual conductors
• Transparent for easy visual inspection of termination
