  11. Straight Blade Plug, 5-30P, 30 A, 125V AC, 2 Pole, Screw Terminals, Grounded
Hubbell Wiring Device-Kellems Straight Blade Plug, 5-30P, 30 A, 125V AC, 2 Pole, Screw Terminals, Grounded HBL9309 - main

Straight Blade Plug, 5-30P, 30 A, 125V AC, 2 Pole, Screw Terminals, Grounded

  • Mfr # HBL9309

  • Zoro # G0544424

product price: $83.09
/ea
Free Shipping & Returns

Key Features

Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL9309
Zoro #
G0544424
UPC #
783585015224
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
1.187 in
For Minimum Cable Diameter
0.625 in
Cord Size
0.625 in to 1.187 in
Minimum Wire Size
12 AWG
Maximum Wire Size
4 AWG
Body Length
4.34 in
Dimensions
4.34 in x 2.75 in x 1.88 in
Wire Size
#12 AWG to #4 AWG
Length
4.34 in
Width
2.75 in
Height
1.88 in

Details

Item
Straight Blade Plug
NEMA Plug Configuration
5-30P
Current Rating
30 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Angled
Grounding
Grounded
Housing Color
Black
IP Rating
IP20
Standards
CSA, UL
Resistance Properties
Corrosion Resistant
Phase - Plugs and Receptacles
1
Material
Nylon
NEMA Plug Configuration - Plugs and Receptacles
5-30P
Voltage
125VAC
HP
2.0
Corrosion Resistant
Yes
Special Features
Corrosion resistant
Grade
Industrial
Number of Wires
3
Grade - Plugs and Receptacles
Industrial
Antimicrobial
No
Housing Material
Nylon
UL 94 Flammability Rating
V-2
Insulation Material
Nylon
Horsepower Rating
2 hp
Maximum Operating Temperature
167 Degrees F
Minimum Operating Temperature
-40 Degrees F
Polarized
Yes
Market
Commercial, Industrial
Temp. Rise
Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%..
Operating Temp.
Maximum continuous 75°C, minimum -40°C (w/o impact).
Flammability
UL 94 HB
Contact Blades Material
.060" Brass
Box Terminals Material
Brass
Retainer Material
Reinforced Thermoplastic Polyester
Ground Contact Blade Material
.078" Brass (.078")
Ground Screw Material
Plated Steel
Weight (Lbs.)
0.55
Body Style
Angle
Dielectric Strength
Withstands 2,000V minimum
Cord Clamp Material
Reinforced Thermoplastic Polyester
Terminal Screw Material
Steel - Zn plated
Blade Holder Material
Reinforced Thermoplastic Polyester
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 V-2 Environmental - IP Suitability - IP20 Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #12-#4 AWG copper stranded or solid conductor only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Wattage
3750 W
Horsepower - Maximum
2
OEM Brand Name
Hubbell Wiring Device-Kellems

Description

Angle Straight Blade Plug, Connection Orientation Angled, Current Rating 30 A, Grounding Grounded, Horsepower Rating 2 hp, Housing Color Black, IP Rating IP20, NEMA Plug Configuration 5-30P, Number of Blades 3, Number of Poles 2, Phase Single, Polarized Yes, Resistance Properties Corrosion Resistant, UL 94 Flammability Rating V-2, Voltage Rating 125V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, For Maximum Cable Diameter 1.187 in, For Minimum Cable Diameter 0.625 in
