  11. Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded
Hubbell Wiring Device-Kellems Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded HBL415 - main

Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded

  • Mfr # HBL415

  • Zoro # G0983832

product price: $32.35
/ea

Key Features

Receptacle Type
Quad
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL415
Zoro #
G0983832
UPC #
783585014081
Country of Origin
United States

Dimensions

Height
4.30 in
Width
0.92 in
Face Plate Height
4.3 in
Minimum Wire Size
14 AWG
Mount Hole Center-to-Center Width
3.4 in
Mount Hole Center-to-Center Height
3.4 in
Face Plate Width
4.3 in
Overall Depth
4.3 in
Maximum Wire Size
12 AWG
Wire Size
#14 AWG to #12 AWG
Dimensions
4.30 in x 0.92 in x 4.30 in
Length
4.30 in
Display Size
Standard Sized Product

Details

Item
Straight Blade Receptacle
Receptacle Type
Quad
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back
Grounding
Grounded
Housing Color
Brown
Mount Type
Flush
IP Rating
Not Rated
Standards
CSA C22.2 No. 42, NEMA WD-6, UL 498
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Wiring Method - Plugs and Receptacles
Back
Mounting Type - Plugs and Receptacles
Surface
Material
polycarbonate
Corrosion Resistant
No
HP
1/2 hp
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Power Indicator
No
Sub-Category
Four Outlet Receptacles
Number of Gangs
2
Outlet Type - Plugs and Receptacles
Quad
Surge Suppression
No
Tamper Resistant
No
Weather Resistant
No
Application Environment
Commercial
NEMA Configuration
5-15
Voltage
125VAC
Weather Resistant - Plugs and Receptacles
No
Mounting Type
Surface
Outlet Type
Quad
Horsepower Rating
1/2 hp
AFCI
No
For Location
Indoor
Grade
Federal Specification
Minimum Operating Temperature
-40 Degrees F
UL 94 Flammability Rating
V-2
Contact Material
Brass
Housing Material
Polycarbonate
Number of Outlets
4
Maximum Operating Temperature
167 Degrees F
NEMA Enclosure Rating
1
Surge Protection
No
Market
Commercial, Industrial
Shrouded
No
Includes
4-PLEX Adapter Plate, 4-PLEX Portable Box
Cover Type
No Cover
Connection Orientation
Straight
GFCI
No
Polarized
Yes
Poles and Wires
2 Pole, 3-Wire Grounding
Dielectric Voltage
Withstands 2,000V minimum
Receptacle Style
Quad
Standard
NEMA
Top Material
Polycarbonate
Power Contacts Material
.032" (.81) Brass
Base Material
Polycarbonate
Receptacle Grade
Heavy Duty Spec Grade
Other Available Colors
Brown, Black, Gray, Ivory, White
Rating
15A, 125V
Current Interrupting
Capable of withstanding a fault level of 1000A, per UL498
Terminal Screw Material
#8-32 Brass, Multiple Drive
Operating Temperatures
Maximum continuous 75°C; minimum -40°C (w/o impact)
Ground Screw Material
#8-32 Brass, Multiple Drive (Green)
Terminal Identification
Terminals identified in accordance with UL 498 and CSA
Flammability
UL 94 V-2
Certification
Listed to UL Standard 498 File E2186 Certified to CSA 22.2, No. 42 File 285
Horsepower
0.5
Terminal Accommodation
#14-12 AWG stranded or solid copper conductor only
Device Color
Brown
Temperature Rise
Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%..
Material - Mounting Hardware
Screw Mounting
Series
4-Outlet Receptacle
Wattage
1875 W
Industry Standard(s)
Certified to CSA 22.2, No. 42 File 285 Listed to UL Standard 498 File E2186 NEMA® WD-6 Compliant
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Performance
Electrical - Current Interrupting - Capable of withstanding a fault level of 1000A, per UL498 Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 V-2 Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #14-12 AWG stranded or solid copper conductor only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Dielectric Strength
Withstands 2,000V minimum
Application
Industrial
Nema Rating
5-15R
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
OEM Brand Name
Hubbell Wiring Device-Kellems
Horsepower - Maximum
0.5

Description

• Anchor hole and loop feature secures solid wire for fast, easy terminations
• Triple wipe contacts
• Easily accessible break-off tabs for split wiring
• Three conductors energize all four outlets
