  11. Wall Switch, 1-Pole, Wiring Module, 20A, Red
Hubbell Wiring Device-Kellems Wall Switch, 1-Pole, Wiring Module, 20A, Red SNAP1221R - main

Wall Switch, 1-Pole, Wiring Module, 20A, Red

  • Mfr # SNAP1221R

  • Zoro # G4568487

product price: $11.15
/ea

Key Features

Switch Type
Single Pole
Switch Style
Toggle
Amps AC
20 A
Color
Red
Voltage AC
120 to 277
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
SNAP1221R
Zoro #
G4568487
UPC #
783585189352
Country of Origin
United States

Dimensions

Overall Height
1.7 in
Overall Width
1.3 in
Height
1.74 in
Width
1.3 in
Length
4.18 in
Dimensions
4.18 in x 1.3 in x 1.74 in

Details

Item
Wall Switch
Switch Type
Single Pole
Switch Style
Toggle
Amps AC
20 A
Color
Red
Voltage AC
120 to 277
Locking
No
Switch Function
Maintained
Wiring Method
Back
Application Environment
Commercial
Rated HP
1 to 2
Antimicrobial
No
Description/Special Features
Abuse-Resistant Thermoplastic Rocker for Heavy-Duty Applications
Standards
UL Listed
Number of Switches
1
Maximum Operating Temperature
75 Degrees C
Features
Automatic Self-Grounding Staple Assures Continuity to Wall Box
Grounding
Grounded
Current Rating
20 A
Resistance Properties
Impact Resistant
Market
Industrial
Minimum Operating Temperature
-40 Degrees F
Wire Connection Type
Modular Wiring
Horsepower Rating
2 hp
Voltage Rating
120/277V AC
Housing Material
Thermoplastic
Style
Single Pole
Type
Toggle
Top Material
Thermoplastic, Red
Max. Continuous Current
20A
Terminals
Brass
Contacts
Silver Alloy
Terminal Accommodations
Uses SNAPConnect Connector
Temperature Rise
30°C maximum at rated current
Dielectric Voltage
Withstands 1500V AC minimum for 1 minute
Toggle Color
Red
Overload
Minimum 4.8 times rated current for 100 cycles
Flammability
UL 94V-2
Max. Working Voltage
277V AC
Base Material
Thermoplastic, Black
Toggle Material
Thermoplastic
Operating Temperature
Max. continuous: 75°C; Min. continuous: -40°C without impact
Series
General Purpose
Material
Thermoplastic
Number Of Poles
Single Pole
Amperage Rating
20 A
Item Type
Single Pole Toggle Switch
Performance
Electrical - Dielectric Voltage - Withstands 1500V AC minimum for 1 minute Electrical - Max. Continuous Current - 20A Electrical - Max. Working Voltage - 277V AC Electrical - Overload - Minimum 4.8 times rated current for 100 cycles Electrical - Temperature Rise - 30°C maximum at rated current Environmental - Flammability - UL 94V-2 Environmental - Operating Temperature - Max. continuous: 75°C, Min. continuous: -40°C without impact Mechanical - Terminal Accommodations - Uses SNAPConnect Connector
Temperature Rise - Max.
30°C maximum at rated current
Current / Amperage Rating
20 A
Voltage Rating Description
120-277 VAC
Industry Standard(s)
UL Listed
Dielectric Strength
Withstands 1500V AC minimum for 1 minute

Description

Wall Switch, Color Red, Current Rating 20 A, Switch Function Maintained, Switch Type Single Pole, Voltage Rating 120/277V AC, Wiring Method Back, Horsepower Rating 2 hp, Locking Style Not Applicable, Number of Switches 1, Resistance Properties Impact Resistant, Standards UL Listed, Switch Style Toggle, Wire Connection Type Modular Wiring, Features Automatic Self-Grounding Staple Assures Continuity to Wall Box, Grounding Grounded, Housing Material Thermoplastic, Market Industrial
