Shop HUBBELL WIRING DEVICE-KELLEMS

Watertight Pin & Sleeve Plug, 60 A, 480V AC, Single Phase, 2 Pole, IEC Grounding, Red, NEMA 4X

  • Mfr # HBLS360C7W

  • Zoro # G0977197

product price:
$
778.99
/ea
Free Shipping & Returns

Key Features

Number of Poles
2
Number of Wires
3
IP Rating
IP68, IP69K
Wire Connection Type
Screw Terminals
Connection Orientation
Straight
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
HBLS360C7W
Zoro #
G0977197
UPC #
783585478524
Country of Origin
United States

Dimensions

For Minimum Cable Diameter
0.5 in
Outside Diameter
5.17 in
Overall Length
12.22 in
Minimum Wire Size
8 AWG
For Maximum Cable Diameter
1.45 in
Maximum Wire Size
2 AWG
Wire Rope Length
12.22 in
Length
12.22 in

Details

Item
Watertight Pin & Sleeve Plug
Current Rating
60 A
Voltage Rating
480V AC
Phase
Single
Number of Poles
2
Number of Wires
3
IP Rating
IP68, IP69K
Wire Connection Type
Screw Terminals
Connection Orientation
Straight
Housing Color
Red
Cap Type
Spring-Loaded Cap
Standards
CSA Certified LR280C, UL Classified to IEC 60309-1 IEC 60309-2, UL E146033
Resistance Properties
Corrosion Resistant, Impact Resistant, Moisture Resistant, Watertight
Grounding Style
IEC
Switch Rated
Yes
Features
Spring-Loaded Disconnect Button
Body Material - Pin and Sleeve
Valox 357
Power Indication
Yes
HP
15 hp
Body Material
Valox 357
Compatible with Series
Advantage Switch-Rated
Horsepower Rating
15 hp
Reverse Service
No
Market
Industrial
NEMA Enclosure Rating
4X
Shrouded
Yes
Maximum Operating Temperature
75 Degrees C
Minimum Operating Temperature
-40 Degrees F
Power Indicating Light
Yes
Contact Material
Beryllium Copper
For Environment
Wet
Housing Material
PBT
Housing Material Grade
Valox 357
Style
IP69k NEMA 4X
Series
Advantage Switch-Rated
Grounding
Grounded
UL 94 Flammability Rating
V-0

Description

The HUBBELL AdvantageTM Series Watertight Pin & Sleeve Plug is a 60A, 480V AC connector rated for use in wet locations according to manufacturer specifications. This plug features a compact and robust PBT housing with Valox 357 grade material, constructed with PBT housing (Valox 357 grade) as specified by the manufacturer; see technical documentation for environmental ratings. It is compatible with IEC 60309-2 devices and rated as switch-rated for disconnecting motor and branch circuits.


Key Features of the HUBBELL AdvantageTM Series Watertight Pin & Sleeve Plug:

  • Current/Voltage Rating: Rated for 60 A at 480V AC single phase

  • Poles/Wires: 2 poles, 3 wires configuration

  • Housing Material: Valox 357 (PBT) housing per product specification

  • NEMA/IP Ratings: NEMA Type 4X enclosure; IP68 and IP69K watertight ratings

  • Operating Temperature Range: -40°C to +75°C

  • Cable Accommodation: Accepts cable diameters from 0.5 in to 1.45 in; wire size range from #8 AWG to #2 AWG

  • Contact Material: Beryllium copper contacts with screw terminal connections

  • Power Indication: Power indication via integrated LED lights

  • Switch-Rated Functionality: Switch-rated functionality per applicable standards; can be used as a disconnecting means for motors and branch circuits when installed according to code requirements

  • Grounding Style: IEC grounding; shrouded design per product specification enhances connection security

  • Spring-Loaded Disconnect Button and Cap provide secure closure when not in use
