  6. Watertight Pin & Sleeve Receptacle, 60 A, 347/600V AC, Three Phase, 4 Pole, IEC Grounding, Black
Hubbell Wiring Device-Kellems Watertight Pin & Sleeve Receptacle, 60 A, 347/600V AC, Three Phase, 4 Pole, IEC Grounding, Black HBL560R5W - main

Watertight Pin & Sleeve Receptacle, 60 A, 347/600V AC, Three Phase, 4 Pole, IEC Grounding, Black

  • Mfr # HBL560R5W

  • Zoro # G0736757

product price:  $580.50
/ea
Free Shipping & Returns

Key Features

Phase
Three
Number of Poles
4
Number of Wires
5
IP Rating
IP67
NEMA Enclosure Rating
Not Rated
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
HBL560R5W
Zoro #
G0736757
UPC #
783585405711
Country of Origin
United States

Dimensions

Minimum Wire Size
8 AWG
Maximum Wire Size
2 AWG
Face Diameter
4.15 in
Cord Size
8 to 2 AWG
Wire Size
#8 AWG to #2 AWG
Display Size
Standard Sized Product

Details

Item
Watertight Pin & Sleeve Receptacle
Current Rating
60 A
Voltage Rating
347/600V AC
Phase
Three
Number of Poles
4
Number of Wires
5
IP Rating
IP67
NEMA Enclosure Rating
Not Rated
Wire Connection Type
Screw Terminals
Housing Color
Black
Cap Type
Spring-Loaded Cap
Standards
CSA Certified C22.2 No. 0.17, CSA Certified C22.2 No. 182.1, IEC 60309-1, UL 1682, UL 94
Resistance Properties
Impact Resistant, Moisture Resistant, Watertight
Switch Rated
No
Grounding Style
IEC
Features
Color Coded
Body Material
Zytel 101 Nylon
HP
15 hp
Body Material - Pin and Sleeve
Zytel 101 Nylon
Material
Thermoplastic
Market
Industrial
Horsepower Rating
25 hp
Reverse Service
No
Minimum Operating Temperature
-40 Degrees C
Power Indicating Light
No
Number of Gangs
1
Shrouded
Yes
Maximum Operating Temperature
75 Degrees C
Flange Type
Flanged
Housing Material
Thermoplastic
Connection Orientation
Straight
Housing Material Grade
Zytel 101
Gasket Material
Neoprene
Weight
2.5 lb
Screw Material
300 Stainless Steel
Service
Standard
Flammability
UL 94 5VA, UL 94 V0
Retainer Material
High-Impact Thermoset
Flange Material
Zytel 101 Nylon
Product Type
Watertight IEC Device
UV Resistance
All Materials are UV Stabilized
Temp. Rise
30°C
Dielectric Strength
3000V AC
Operating Temp.
-40 to 75°C
Application
High Ampacity Watertight Connections
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstand 3000V AC Electrical - Max. Working Voltage - 600V RMS Environmental - Flammability - HB or better per UL 94 or CSA C22.2 No. 0.17 Environmental - Ingress Protection - IP67 Suitability Environmental - Moisture Resistance - Watertight per IEC 60309-1 Environmental - Operating Temperatures - Maximum Continuous 75°C Minimum - 40°C w/o impact Mechanical - Impact Resistance - Per CSA C22.2 No. 182.1 / UL1682 Mechanical - Product Identification - Ratings are a permanent part of the device housing Mechanical - Terminal Identification - Terminals identified in accordance with North American and IEC conventions Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstand 3000V AC Electrical - Max. Working Voltage - 600V RMS Environmental - Flammability -V-0 Environmental - Ingress Protection - Type 3R, 3RX, 4X and IP68, IP69k Suitability Environmental - Moisture Resistance - Watertight per IEC 60309-1 Environmental - Operating Temperatures - Maximum Continuous 75°C Minimum - 40°C w/o impact Mechanical - Impact Resistance - Per CSA C22.2 No. 182.1 / UL1682 Mechanical - Product Identification - Ratings are a permanent part of the device housing Mechanical - Terminal Identification - Terminals identified in accordance with North American and IEC conventions
Wattage
36000
Series
HBL Heavy Duty
Number Of Conductors
5-Wire Grounding
Environmental Conditions
Watertight
OEM Brand Name
Hubbell Wiring Device-Kellems
Industry Standard(s)
Listed To Standard UL1682
Insulation
Insulated Body
Style
Standard Service
Material - Mounting Hardware
Screw Mounting
Connection Type
Screw Terminals

Description

Watertight Devices - Hubbell’s IEC 60309 Pin and Sleeve plugs, connectors, inlets and receptacles are the highest performing products available. The HBL® series of IEC pin and sleeve were designed for the demanding North American market. Hubbell was the first and is still only manufacturer of IEC 60309 devices in the USA and have numerous innovative features noted below. The IEC line of plugs and connectors are made with a rugged super tough, one-piece housing. The thermoset polyester contact carrier provides a high resistance to electrical tracking. They withstand higher temperatures which may result from overload or arcing. The heavy-duty, external cord grip provides superior strain relief on the conductors. Hubbell’s horsepower rated plugs and receptacles meet NEC 430.109(F) requirements and recognized as an approved disconnecting “line of sight” disconnecting means.
• Self-closing gasketed cover
• Color coded housings for easy identification
• Super tough insulated non-metallic housing
