Pillow Block Ball Bearing Mounted Unit, Ball, 30 mm Dia
- Mfr # HUCP206-30MM
- Zoro # G212006675
product price:Â
$
70.79
/ea
Key Features
System of Measurement
Metric
Shaft Locking Type
Set Screw
Bearing Insert Type
Ball
Bore Diameter
30 mm
Center Height
42.9 mm
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- HUCP206-30MM
- Zoro #
- G212006675
- UPC #
- -
- Country of Origin
- China
- System of Measurement
- Metric
- Item
- Pillow Block Ball Bearing Mounted Unit
- Shaft Locking Type
- Set Screw
- Bearing Insert Type
- Ball
- Resistance Properties
- Corrosion-Resistant, High Temperature-Resistant
- Seal Material
- Silicone Rubber
- Maximum Temperature
- 450 Degrees F
- Features
- C4 Internal Clearance to Accommodate Thermal Expansion, Specially Heat Treated Rings
- Minimum Temperature
- -45 Degrees F
- Bearing Insert Material
- Alloy Steel
- Number of Mount Holes
- 2
- For Environment
- Extreme High Temperature
- Includes
- (2) Set Screws
- Split Housing
- Not Split
- Housing Material
- Cast Iron
- Expansion Type
- Fixed
- Included Bearing
- HUC206-30MM
- Maximum Speed
- 5,000 RPM
- Bearing Lubrication
- Relubricateable
- Internal Clearance
- C3
Dimensions
- Bore Diameter
- 30 mm
- Center Height
- 42.9 mm
- Mount Hole Center-to-Center Length
- 121 mm
- Overall Length
- 160 mm
- Overall Width
- 44 mm
- Overall Height
- 84 mm
- Mounting Bolt Size
- 1/2 in
- Wire Rope Length
- 160 mm
- Length
- 160 mm
- Fits Chest Size
- C4 Internal Clearance to Accommodate Thermal Expansion, Specially Heat Treated Rings
Description
Pillow Block Bearing, Bearing Insert Material Alloy Steel, Bearing Insert Type Ball, Bore Diameter 30 mm, Center Height 42.9 mm, Expansion Type Fixed, For Environment Extreme High Temperature, Housing Material Cast Iron, Included Bearing HUC206-30MM, Maximum Speed 5,000 RPM, Maximum Temperature 450 Degrees F, Minimum Temperature -45 Degrees F, Mount Hole Center-to-Center Length 121 mm, Number of Mount Holes 2, Overall Height 84 mm, Overall Length 160 mm, Overall Width 44 mm
