Shop JAN FAN

MountedFan, Yellow, 20inDia, Steel, 3Blade

  • Mfr # JF-AKF20-DCS-S
  • Zoro # G122587097
product price:
$
756.99
/ea
Free Shipping & Returns

Key Features

Assembly Required
Yes
Features
Modular Design for Part Interchangeability, Positive Locking Guard with Quick-Release for Safe Access, Safety Cable for Over-Head Mounted Fans, Spring-Type Steel Blades with Front Hub
RPM
900 RPM, 1,100 RPM
Fan Blade Color
Yellow
Thermal Protection
Yes
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
JF-AKF20-DCS-S
Zoro #
G122587097
UPC #
-
Country of Origin
China
Assembly Required
Yes
Features
Modular Design for Part Interchangeability, Positive Locking Guard with Quick-Release for Safe Access, Safety Cable for Over-Head Mounted Fans, Spring-Type Steel Blades with Front Hub
RPM
900 RPM, 1,100 RPM
Fan Blade Color
Yellow
Thermal Protection
Yes
Number of Speeds
2
Air Velocity @ 60 Ft.
100 fpm
Hz
60/50 Hz
Voltage
115 V
Max. Ambient Temp.
104 Degrees F
Includes
Drop Cord Switch
Mount Type
Articulating Arm
Amps
2.4/1.2 A
Mounting Surface
C-Channel, I-Beam
Air Velocity @ 10 Ft.
175 fpm
Wire Guard Finish
Powder Coated
Air Velocity @ 80 Ft.
100 fpm
Number of Conductors
0
NEMA Plug Configuration
5-15P
Guard Material
Steel
Drive Type
Direct Drive
Fan Power Source
Hardwired
Motor HP
1/4 hp
Air Velocity @ 20 Ft.
175 fpm
Motor Enclosure
Totally Enclosed Non-Ventilated
Watts
200/300 W
Airflow
2,818 cfm
Standards
ETL
Environmental Applications
Agricultural, Commercial, Industrial
Item
Mounted Fan
Blade Material
Steel
Color
Silver
Number of Blades
3
Motor Insulation
B
Head Tilt Adjustment
180 Degrees
For Location
Garage, Fitness Center, Greenhouse, Manufacturing Plant, Warehouse
Sound Level
60.2 dB
Air Velocity @ 40 Ft.
150 fpm

Description

Mounted Fan, Non-Oscillating, Voltage 115 V, Air Velocity @ 20 Ft. 175 fpm, Motor HP 1/4 hp, Fan Mounting Location Ceiling, Floor, Wall, Sound Level 60.2 dB, Max. Ambient Temp. 104 Degrees F, Hz 60/50 Hz, Watts 200/300 W, Drive Type Direct Drive, Height 24 5/8 in, Width 24 5/8 in
