This item is Discontinued.

Johnson Controls Electric Ball Valve Actuator, 60 sec. VA9104-IUA-2S

Electric Ball Valve Actuator, 60 sec. (Discontinued)

  • Mfr # VA9104-IUA-2S
  • Zoro # G0314161
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
VA9104-IUA-2S
Zoro #
G0314161
UPC #
-
Country of Origin
Mexico

Dimensions

Width
2 13/16 in
Height
5 11/32 in
Depth
6 1/16 in
Overall Height
5 3/8 in
Stroke Length
Not Rated
Electrical Lead Length
4 ft
Overall Depth
6 1/16 in
Overall Width
2 13/16 in

Details

Item
Electric Ball Valve Actuator
Voltage
100 to 240V AC
Signal Type
On-Off/Floating
Torque
35 in-lb
Cycle Time
60 sec
Ambient Temp. Range
-4 Degrees to 140 Degrees F
Ball Valve Product Group
Actuated
Type of Actuator
Non-Spring Return
Stroke Deg.
93
Standards
CCN XAPX7 File 27734 Plenum Rated Per CSA 22.2 No. 236/UL 1995, cUL
Electrical Connections
48 in Wire
Power Consumption
7.5 VA
Enclosure Rating
NEMA 2
For Use With
VG 1000 Ball Valves
Product Type
Electric Ball Valve Actuator
Application
Air Conditioning, Heating, Ventilation
Operating Temperature - Maximum
140 Degrees F
Operating Temperature - Minimum
-4 Degrees F
Stroke Degree
93 Degrees
Housing Material
Plastic
Compatible Brand
Johnson Controls
Compatible Valve Body Pattern
Three-Way, Two-Way
Number of Auxiliary Switches
0
Includes Electrical Leads
Electrical Leads Included
Frequency
50/60 Hz
Electrical Connection Type
Cable
Mounting Style
Direct Mount
Compatible Valve Action
Normally Closed, Normally Open
Return Action
Non-Spring Return
Control Signal
Floating Point, On/Off
NEMA Rating
1
Compatible Series
VG1000

Description

Electric Ball Valve Actuator, Application Air Conditioning, Heating, Ventilation, Compatible Brand Johnson Controls, Compatible Series VG1000, Compatible Valve Action Normally Closed, Normally Open, Compatible Valve Body Pattern Three-Way, Two-Way, Control Signal Floating Point, On/Off, Cycle Time 60 sec, Electrical Connection Type Cable, Electrical Lead Length 4 ft, Frequency 50/60 Hz, Housing Material Plastic, Includes Electrical Leads Electrical Leads Included, Mounting Style Direct Mount
