  9. Outdoor Air Circulator, Floor Mount, 36 in Blade Dia, 120V, 8350/12,250 cfm, Non-Oscillating
Dayton Outdoor Air Circulator, Floor Mount, 36 in Blade Dia, 120V, 8350/12,250 cfm, Non-Oscillating 2RDZ3 - main

Outdoor Air Circulator, Floor Mount, 36 in Blade Dia, 120V, 8350/12,250 cfm, Non-Oscillating

  • Mfr # 2RDZ3

  • Zoro # G3417416

product price: $726.99
/ea
Free Shipping & Returns

Key Features

Oscillation
Non-Oscillating
Number of Speeds
2
Voltage
120V
Phase
1
Motor HP
1/2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
2RDZ3
Zoro #
G3417416
UPC #
190735229798
Country of Origin
China

Dimensions

Blade Diameter
36 in
Max. Depth
15 in
Outside Dia.
41 in
Width
43 in
Shaft Dia.
5/8 in
Height
43 in
Fan Cord Length
9 ft
Height Adjustment
Fixed Height
Depth
15 in
Wheel Dia.
8 in

Details

Oscillation
Non-Oscillating
Number of Speeds
2
Voltage
120V
Phase
1
Motor HP
1/2
Air Flow
8350/12,250 cfm
Drive Type
Direct Drive
Blade Material
Aluminum
Item
Air Circulator
Air Velocity @ 60 Ft.
210/80 fpm
Standards
UL/cUL Listed, OSHA compliant wire guards
Number of Conductors
3
Mobile/Stationary
Mobile
Max. Ambient Temp.
104 Degrees F
Guard Material
Galvanized Steel
Bearing Type
Sealed Ball
Application
Spot Cooling; Air Circulation
Watts
1.4 W
NEMA Plug Configuration
5-15P with GFCI
Hz
60
Fan Style
Outdoor
CFM High
12250
Environmental Applications
Industrial
Air Velocity @ 40 Ft.
260/220 fpm
Motor Type
Permanent Split Capacitor
Number of Blades
3
Air Velocity @ 20 Ft.
490/370 fpm
Housing Material
Galvanized steel
Motor RPM
825/650 RPM
Thermal Protection
Automatic Reset
Motor Enclosure
Totally Enclosed Air Over
Assembled
Partially Assembled
Fan Mounting Location
Floor
Wire Guard Finish
Polyester Powder Coated
Motor Insulation
Class B
CFM Low
8350
Fan Accessory Style
Outdoor
Includes
Cord Wrap and Tilt Wheel, 8" Steel and Rubber Casters
Assembly Required
Yes
Head Tilt Adjustment
50 Degrees Up to 10 Degrees Down
Wheeled Base
Mobile
Wheel Material
Steel/Rubber
RPM
825/650
Color
Safety Yellow
Fan Housing Material
Steel
Amps
5.3/4.9
Material
Galvanized steel
Motor hp
1/2 hp
NEMA plug Configuration
5-15p with GFCI

Description

High-Visibility Industrial Fan, Blade Dia. 36 in, Mobile, Non-Oscillating, 2 Speeds, Voltage 120V AC, 1 Phase, CFM High 12,250, CFM Low 8350, Air Velocity @ 20 Ft. 490/370 fpm, Motor HP 1/2 hp, Motor RPM 825/650, Operating Amps 5.3/4.9, Fan Mounting Location Floor, Fan Accessory Style Outdoor, Fan RPM 825/650, Max. Ambient Temp. 104 Degrees F, Hz 60 Hz, Watts 615/515, Motor Type Permanent Split Capacitor, Drive Type Direct Drive, Outside Dia. 41 In., Height 43 in, Width 43 in, Max. Depth 15 In.
