  9. LED Driver, 0-10V, 5-9/16 in - L, 1PK
Keystone LED Driver, 0-10V, 5-9/16 in - L, 1PK KTLD-20-UV-SC730-56-VDIM-AF4-CP - main

LED Driver, 0-10V, 5-9/16 in - L, 1PK

  • Mfr # KTLD-20-UV-SC730-56-VDIM-AF4-CP

  • Zoro # G200905928

product price: $37.69
/ea

Key Features

Power Output
20 W
Environmental Rating
Dry Location
Length
5 9/16 in
Width
1 5/16 in
Height
13/16 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
KTLD-20-UV-SC730-56-VDIM-AF4-CP
Zoro #
G200905928
UPC #
843654126678
Country of Origin
China

Dimensions

Length
5 9/16 in
Width
1 5/16 in
Height
13/16 in

Details

Item
LED Driver
Power Output
20 W
Environmental Rating
Dry Location
For Use With
LED Lighting
Input Voltage
120 to 277V AC
Output Technology
Programmable
Output Current
200 to 730 mA
Input Power
20 W
Dimming Range
100% to 1%
Ambient Temp. Range
-40 Degrees to 140 Degrees F
Driver Mounting Location
Remote Mount
Power Factor
Greater Than 0.9
Output Voltage
10 to 56V DC
Input Current
0.23A
Ouput Constant
Programmable
Standards
ANSI C63.4:2009 Class B, EN61000-3-2 (Harmonic Current Emissions Class C), EN61347-1, EN61347-2-13, UL 8750
Dimming
Yes
Driver Class
Class 2
Max. Case Temp.
194 Degrees F
Dimming Method
0-10V
Number of Bulbs Supported
1
Profile
Standard Profile
Intended LED Usage
Fixture Array
Dimming Type
Full Continuous Dimming
Case Form Factor
Compact
Number of Fixtures
1
Power Output - Maximum
20 W
Driver Life Expectancy
85,000 hr
UL Type
Type C
Min. Ambient Temp.
-40 Degrees F
Power Output - Minimum
2 W
Total Harmonic Distortion
20 %
Input Current - Maximum
0.23 A
Max. Ambient Temp.
140 Degrees F
Frequency
60 Hz
Power Factor - Minimum
0.9

Description

LED Driver, Intended LED Usage Fixture Array, Number of Bulbs Supported 1, 120 to 277V AC Input Voltage, 10 to 56V DC Output Voltage, 0.23A Input Current, 200 to 730 mA Output Current, 20 W Input Power, 20 W Power Output, 5 9/16 in Length, 1 5/16 in Width, 13/16 in Height, Case Form Factor Compact, Standard Profile, Class 2

Restrictions

This item has been restricted from sale in the following states: AK, GU, NM, PR, VI
