Keystone LED Driver, 0-10V, 5 in - L, 1PK KTLD-40-UV-SC1400-56-VDIM-W1-CP - main

LED Driver, 0-10V, 5 in - L, 1PK

  • Mfr # KTLD-40-UV-SC1400-56-VDIM-W1-CP

  • Zoro # G100905851

product price:  $37.95
/ea

Key Features

Power Output
40 W
Environmental Rating
Dry Location
Length
5 in
Width
2 3/8 in
Height
1 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
KTLD-40-UV-SC1400-56-VDIM-W1-CP
Zoro #
G100905851
UPC #
890949020524
Country of Origin
China

Dimensions

Length
5 in
Width
2 3/8 in
Height
1 in

Details

Item
LED Driver
Power Output
40 W
Environmental Rating
Dry Location
For Use With
LED Lighting
Input Voltage
120 to 277V AC
Driver Class
Class 2
Dimming
Yes
Input Power
40 W
Max. Case Temp.
194 Degrees F
Standards
ANSI C63.4:2009 Class B, EN61000-3-2 (Harmonic Current Emissions Class C), EN61347-1, EN61347-2-13, UL 8750, UL 1310 Class 2
Input Current
0.22A, 0.24A, 0.49A
Output Technology
Programmable
Dimming Range
100% to 1%
Driver Mounting Location
Remote Mount
Ambient Temp. Range
-4 Degrees to 122 Degrees F
Power Factor
Greater Than 0.9
Output Voltage
10 to 56V DC
Ouput Constant
Programmable
Output Current
470 to 1400 mA
Case Form Factor
Compact
Dimming Method
0-10V
Profile
Standard Profile
Number of Bulbs Supported
1
Intended LED Usage
Fixture Array
Dimming Type
Full Continuous Dimming
Number of Fixtures
1
Total Harmonic Distortion
20 %
Power Output - Maximum
40 W
UL Type
Type C
Power Output - Minimum
4.7 W
Driver Life Expectancy
85,000 hr
Frequency
50/60 Hz
Max. Ambient Temp.
122 Degrees F
Power Factor - Minimum
0.9
Min. Ambient Temp.
-4 Degrees F
Input Current - Maximum
0.49 A

Description

LED Driver, Intended LED Usage Fixture Array, Number of Bulbs Supported 1, 120 to 277V AC Input Voltage, 10 to 56V DC Output Voltage, 0.22A, 0.24A, 0.49A Input Current, 470 to 1400 mA Output Current, 40 W Input Power, 40 W Power Output, 5 in Length, 2 3/8 in Width, 1 in Height, Case Form Factor Compact, Standard Profile, Class 2

Restrictions

This item has been restricted from sale in the following states: AK, GU, NM, PR, VI
