Diamond Turning Insert, Diamond, 2, .5

Name: Diamond Turning Insert, Diamond, 2, .5
Brand: Kyocera
SKU: G7968197
Price: 183.90 USD
Availability: InStock

18.39

/ea

Sold in multiples of 10 for $183.90

Insert Shape

Diamond

Inscribed Circle

1/4 in

Chip-Breaker

Yes

Corner Radius

0.0079 in

Rake

Positive

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Get 10% off your order

Specifications

MFR #: VCGT2205FNZTN60
Zoro #: G7968197
UPC #: -
Country of Origin: Multiple
Item: Diamond Turning Insert
Insert Shape: Diamond
Inscribed Circle: 1/4 in
Chip-Breaker: Yes
Rake: Positive
ISO Number: VCGT110302FN-Z
Cutting Direction: Neutral
Features: General Purpose Cermet with Superior Wear Resistance and Toughness
Secondary Material Application: Stainless Steel
Finish - Machining: Bright (Uncoated)
Material - Machining: Cermet
Cutting Application: Back Boring, Copying, External Turning, Facing, Internal Facing, Profiling, Undercutting
Primary Material Application: Steel
General Shape: Diamond
Number of Cutting Edges: 2
ANSI Code: VCGT2205FNZ
Hole Type: 40 Degrees to 60 Degrees Countersink Through Hole
Insert Holding Type: Screw
Measurement System: Fractional Inch
Shape: Diamond
Primary Material Application ISO Code: P
Manufacturer Grade: TN60
Included Angle: 35 Degrees
Clearance Angle: 7 Degrees
Secondary Material Application ISO Code: M
Cutting Edge: Sharp Edge
Material Grade - Machining: TiCN+NbC Component
Chip-Breaker Code: Z

Diamond Turning Insert, Chip-Breaker Code Z, Inscribed Circle 1/4 in, Bright (Uncoated), ANSI Code VCGT2205FNZ, Clearance Angle 7 Degrees
