Kyocera Diamond Turning Insert, Diamond, 4, CNGA, 3, CBN CNGA433S00730METKBN35M - main

Diamond Turning Insert, Diamond, 4, CNGA, 3, CBN

  • Mfr # CNGA433S00730METKBN35M

  • Zoro # G7435569

product price: $79.59
/ea
Free Shipping & Returns

Key Features

Insert Shape
Diamond
Insert Style
CNGA
Inscribed Circle
4
Insert Size
433
Chip-Breaker
Yes
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CNGA433S00730METKBN35M
Zoro #
G7435569
UPC #
-
Country of Origin
Multiple

Dimensions

Insert Size
433
Corner Radius
3
Insert Thickness
0.188"
Nose Radius
0.0469"
Mounting Hole Dia.
0.203"
Thickness
3

Details

Item
Diamond Turning Insert
Insert Shape
Diamond
Insert Style
CNGA
Inscribed Circle
4
Chip-Breaker
Yes
Grade
KBN35M
Insert Material
CBN
Insert Application
Finishing
Rake
Negative
ISO Number
CNGA120412S01730ME-T
ANSI Number
CNGA433S00730METKBN35M
Cutting Direction
Neutral
Relief Angle
0 Degrees
No. of Edges
2
Workpiece Compatibility
Hardened (H)
Steel (P) Compatibility
No
For Use With
Mfr. No. DCLNR/L 12-4B, DCLNR/L 16-4D, MCLNR/L 12-4B, MCLNR/L 16-4D, PCLNR/L 12-4B, PCLNR/L 16-4D, A-DCLNR/L 4, S-PCLNR/L 4
Coating
Megacoat
Non Ferrous (N) Compatibility
No
Hardened (H) Compatibility
Yes
Mounting Style
Rigid Clamp
Super Alloy (S) Compatibility
No
Cast Iron (K) Compatibility
No
Stainless (M) Compatibility
No
Shape
Rhombic
Manufacturer Grade
KBN35M
Measurement System
Fractional Inch
Cutting Application
Turning
Insert Holding Type
Screw
Material - Machining
CBN
Included Angle
80 Degrees
Features
Wear Resistant
Primary Material Application
Hardened Steel
Primary Material Application ISO Code
H
Clearance Angle
0 Degrees
Number of Cutting Edges
2
ANSI Code
CNGA433S00730METKBN35M
Finish - Machining
Megacoat Nano
Chip-Breaker Code
ME
Material
CBN

Description

Diamond Turning Insert, Chip-Breaker Code ME, Inscribed Circle 1/2 in, Megacoat Nano, ANSI Code CNGA433S00730METKBN35M, Clearance Angle 0 Degrees
