Leeson GP Motor, Cap-Strt, 1/2 HP, 115/208-230 V 056C34F5301 - main

GP Motor, Cap-Strt, 1/2 HP, 115/208-230 V

  • Mfr # 056C34F5301

  • Zoro # G9181934

product price: $286.78
/ea
Free Shipping & Returns

Key Features

Overall Length
11 7/8 in
RPM Group
3001-3600
Motor Service Factor
1.15
Motor Mounting Position
Horizontal
Motor Application
General Purpose
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
056C34F5301
Zoro #
G9181934
UPC #
-
Country of Origin
Mexico

Dimensions

Overall Length
11 7/8 in
Manufacturers Warranty Length
1 yr
Length Less Shaft
9 3/4 in
Shaft Length
2 1/16 in
Shaft Dia.
5/8 in

Details

RPM Group
3001-3600
Motor Service Factor
1.15
Motor Mounting Position
Horizontal
Motor Application
General Purpose
Motor Enclosure Design
Totally Enclosed Fan Cooled
Inverter Rated
Not Inverter Rated
Phase
Single
Ins. Class
B
Item
General Purpose Motor
Hz
60 Hz
Max. Ambient Temp.
40 Degrees C
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC
Nominal Efficiency
59.5 %
Motor Shaft Rotation
CW/CCW
HP
1/2 hp
Motor Thermal Protection
None
Nameplate RPM
3,450 RPM
Full Load Amps
8.4/4.2-4.0 A
Motor Bearings
Ball
Voltage
115/208-230V AC
Frame
56C
Motor Frame Material
Steel
Duty
Continuous
Frame Material
Rolled steel
Includes
Brake, Capacitor
No. of Speeds
1
Standards
CE, CSA, UL Recognized
Motor Design
Capacitor-Start
RPM Range
3,001-3,600
Motor Mounting Type
C-Face, Rigid Base
Motor Shaft Design
Keyed
Weight
22 lb
Usable @ 200V
Not Usable at 200V
Duty Cycle
Continuous
Usable @ 208V
Usable at 208V
Capacitor Required
Yes

Description

General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/2 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 8.4/4.2-4.0 A, 56C Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
