  11. HazardousLocationMotor, 1hp, 3450RPM
No Product Image Available

HazardousLocationMotor, 1hp, 3450RPM

  • Mfr # 119424.00

  • Zoro # G211935594

product price: $1,210.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Three-Phase
Phase
Three
HP
1 hp
RPM Range
3,001-3,600
Voltage
230V AC, 460V AC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
119424.00
Zoro #
G211935594
UPC #
691720046937
Country of Origin
Mexico

Dimensions

Lead Length
6 in
Overall Length
14 7/16 in
Length Less Shaft
12 in
Shaft Length
2 9/16 in
Shaft Dia.
5/8 in

Details

Motor Design
Three-Phase
Phase
Three
HP
1 hp
RPM Range
3,001-3,600
Voltage
230V AC, 460V AC
Frame
56J
Hazardous Location Class
Class I, Class II
Motor Thermal Protection
Auto
Motor Enclosure Design
Totally Enclosed Fan Cooled
Motor Mounting Type
C-Face
Voltage @ 50Hz
190/380V AC
Full Load Amps @ 50Hz
1.5 A
Motor Shaft Rotation
CW/CCW
Voltage Compatibility
230V AC, 460V AC
Motor Service Factor
1
Motor Frame Material
Steel
CC Number
Not Available
RPM @ 50Hz
2,850 RPM
NEMA Design
B
Hazardous Location Division
Division I
Motor Bearings
Ball
Usable @ 200V
Not Usable at 200V
Service Factor @ 50Hz
1
HP @ 50Hz
3/4 hp
Standards
CSA Certified, UL Listed
Motor Shaft Design
Threaded
Usable @ 208V
Not Usable at 208V
Nameplate RPM
3,450 RPM
Max. Ambient Temp.
40 Degrees C
Conduit Box Location
Not available
Nominal Efficiency
80 %
Weight
40 lb
Motor Mounting Position
Horizontal
Full Load Amps
1.5 A
No. of Speeds
1
Includes
Explosion Proof Conduit Box
Item
Hazardous Location Motor
Motor Application
Hazardous Location
Temp. Code
T3B
Duty Cycle
Continuous
Ins. Class
B
Hz
60/50 Hz
Hazardous Location Group
Group C, Group D, Group F, Group G

Description

Hazardous Location Motor, Three Phase, Motor Design Three-Phase, 1 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 230V AC, 460V AC, Full Load Amps 1.5 A, 56J Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60/50 Hz, Max. Ambient Temp. 40 Degrees C, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Hazardous Location Class Class I, Class II, Temp. Code T3B, Motor Enclosure Design Totally Enclosed Fan Cooled, Duty Cycle Continuous
