  11. HazLoc Motor, 3-Ph, 1/4 HP, 1725 RPM, 56C
Leeson HazLoc Motor, 3-Ph, 1/4 HP, 1725 RPM, 56C 056T17E5310 - main

HazLoc Motor, 3-Ph, 1/4 HP, 1725 RPM, 56C

  • Mfr # 056T17E5310

  • Zoro # G5759957

product price: $458.51
/ea
Free Shipping & Returns

Key Features

Motor Design
Three-Phase
Phase
Three
HP
1/4 hp
RPM Range
1,701-1,800
Voltage
208-230/460V AC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
056T17E5310
Zoro #
G5759957
UPC #
-
Country of Origin
Mexico

Dimensions

Shaft Dia.
5/8 in
Shaft Length
1 7/8 in
Overall Length
12 in
Length Less Shaft
9 15/16 in
Lead Length
18 in

Details

Motor Design
Three-Phase
Phase
Three
HP
1/4 hp
RPM Range
1,701-1,800
Voltage
208-230/460V AC
Frame
56C
Hazardous Location Class
Class I, Class II
Motor Thermal Protection
Auto
Motor Enclosure Design
Totally Enclosed Non-Ventilated
Motor Mounting Type
C-Face
Temp. Code
T3B
Motor Shaft Design
Keyed
Standards
CSA Certified, UL Listed
Nameplate RPM
1,725 RPM
Includes
(13) 18 in Leads through 1 in NPT Nipple, Conduit Box
Motor Shaft Rotation
CW/CCW
Duty
Continuous
Max. Ambient Temp.
40 Degrees C
Frame Material
Rolled steel
Motor Application
Hazardous Location
Ins. Class
B
Item
Hazardous Location Motor
Motor Efficiency Group
Standard Efficient
Motor Frame Material
Steel
NEMA Design
B
Full Load Amps
1.1-1.1/0.55 A
Voltage Compatibility
208-220/440V AC, 208-230/460V AC, 208-230V AC, 208-240V AC, 208V AC, 220-230/460V AC, 220/460V AC, 230/460V AC, 230V AC, 240V AC, 460V AC
Motor Service Factor
1
Hz
60 Hz
Motor Bearings
Ball
Nominal Efficiency
75 %
Usable @ 200V
Not Usable at 200V
Weight
71 lb
Duty Cycle
Continuous
Hazardous Location Division
Division I
Conduit Box Location
Exterior
Motor Mounting Position
Horizontal
No. of Speeds
1
Usable @ 208V
Usable at 208V
Hazardous Location Group
Group C, Group D, Group F, Group G

Description

Hazardous Location Motor, Three Phase, Motor Design Three-Phase, 1/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 208-230/460V AC, Full Load Amps 1.1-1.1/0.55 A, 56C Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Max. Ambient Temp. 40 Degrees C, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Hazardous Location Class Class I, Class II, Temp. Code T3B, Motor Enclosure Design Totally Enclosed Non-Ventilated, Duty Cycle Continuous
