  6. Washdown Motor, 3-Phase, 1 HP, 208-230/460V AC, 1,750 Nameplate RPM, 56HC Frame
Leeson Washdown Motor, 3-Phase, 1 HP, 208-230/460V AC, 1,750 Nameplate RPM, 56HC Frame 119785.00 - main

Washdown Motor, 3-Phase, 1 HP, 208-230/460V AC, 1,750 Nameplate RPM, 56HC Frame

  • Mfr # 119785.00

  • Zoro # G4608296

product price:  $5,936.99
/ea
Additional $165.00 delivery surcharge applies per item.
See details

Key Features

Motor Design
3-Phase
Phase
Three
HP
1
RPM Range
1,701-1,800
Voltage
208-230/460V AC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
119785.00
Zoro #
G4608296
UPC #
691720018941
Country of Origin
Mexico

Dimensions

Shaft Dia.
5/8 in
Shaft Length
1 7/8 in
Overall Length
18 in
Length Less Shaft
6 1/8 in
Manufacturers Warranty Length
1 yr

Details

Item
Washdown Motor
Motor Design
3-Phase
Phase
Three
HP
1
RPM Range
1,701-1,800
Voltage
208-230/460V AC
Frame
56HC
Motor Service Factor
1.15
Motor Thermal Protection
None
Motor Enclosure Design
Totally Enclosed Non-Ventilated
Nameplate RPM
1,750
Motor Application
Farm Duty
Motor Frame Material
Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Rigid Base
Motor Sub Application
Extra High Torque
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Standards
CSA (LR2025), UL (E49747)
Voltage Compatibility
200-230/440V AC, 200-230/460V AC, 208-230/460V AC, 460V AC
Motor Efficiency Group
Standard Efficient
Item - Farm Duty Motors
Washdown Motor
Nominal Efficiency
82.5 %
Finish
Enamel
Ins. Class
F
Duty
Continuous
Motor Bearings
Ball
Max. Ambient Temperature
40 Degrees C
Hz
60/50 Hz
Full Load Amps
3.0-2.8/1.4 A
Frame Material
Rolled steel
Capacitor Required
Yes
Usable @ 200V
No
Usable @ 208V
Yes
Duty Cycle
Continuous
Max. Ambient Temp.
40 Degrees C
No. of Speeds
1
Weight
73 lb

Description

Farm Duty Motor, Three Phase, Motor Design Three-Phase, 1 hp HP, Nameplate RPM 1,750 RPM, No. of Speeds 1, Voltage 208-230/460V AC, Full Load Amps 3.0-2.8/1.4 A, 56HC Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, 60/50 Hz Hz, Motor Service Factor 1.15, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Non-Ventilated, Motor Mounting Type Rigid Base
