  11. WashdownMotor, 1/3hp, 1725RPM, 230/460VAC
No Product Image Available

WashdownMotor, 1/3hp, 1725RPM, 230/460VAC

  • Mfr # 116642.00

  • Zoro # G511931210

product price: $665.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Three-Phase
Phase
Three
HP
1/3 hp
RPM Range
1,701-1,800
Voltage
230/460V AC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
116642.00
Zoro #
G511931210
UPC #
691720343463
Country of Origin
United States

Dimensions

Shaft Dia.
5/8 in
Stud Size
3/8"-16
Length Less Shaft
8 1/2 in
Manufacturers Warranty Length
Not available
Overall Length
10 7/8 in
Body Dia.
7.4 in
Shaft Length
2 1/16 in
Bolt Circle Dia.
5 7/8 in

Details

Item
Washdown Motor
Motor Design
Three-Phase
Phase
Three
HP
1/3 hp
RPM Range
1,701-1,800
Voltage
230/460V AC
Frame
56C
Motor Frame Material
Steel
Motor Thermal Protection
None
Motor Enclosure Design
Totally Enclosed Fan Cooled
Usable @ 208V
Not Usable at 208V
NEMA Design
B
Ins. Class
F
Motor Bearings
Ball
Voltage Compatibility
230V AC, 460V AC
RPM @ 50Hz
1,425 RPM
Motor Shaft Design
Keyed
Full Load Amps @ 50Hz
0.86 A
Motor Mounting Type
C-Face
Motor Mounting Position
Horizontal
Motor Shaft Rotation
CW/CCW
Service Factor @ 50Hz
1.15
Nominal Efficiency
62 %
HP @ 50Hz
1/4 hp
Bearing Protection
Not available
Motor Service Factor
1.15
Duty Cycle
Continuous
Voltage @ 50Hz
190/380V AC
Weight
19 lb
Full Load Amps
1.8/0.9 A
Finish
Epoxy-Coated
Shaft Material
Stainless Steel
Endshield Material
Aluminum
Standards
CE, CSA Certified, UL Listed, USDA Approved
Usable @ 200V
Not Usable at 200V
Nameplate RPM
1,725 RPM
Includes
Not available
No. of Speeds
1
Max. Ambient Temp.
40 Degrees C
Hz
60/50 Hz
Motor Application
General Purpose
Conduit Box Position
F1

Description

Washdown Motor, Three Phase, Motor Design Three-Phase, 1/3 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 1.8/0.9 A, 56C Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60/50 Hz Hz, Motor Service Factor 1.15, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, NEMA Design B, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Mounting Type C-Face
