Shop LEGRAND

TURNLOK

  • Mfr # 4716SS
  • Zoro # G322785088
product price:
$
31.89
/ea

Key Features

Grounding
Grounded
NEMA Plug Configuration
L5-15P
Shrouded
No
Minimum Wire Size
10 AWG
Polarized
Yes
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
4716SS
Zoro #
G322785088
UPC #
785007471618
Country of Origin
Mexico

Dimensions

Minimum Wire Size
10 AWG
Flange Diameter
2.56 in
Mount Hole Center-to-Center Width
2 in
Overall Depth
1.66 in
Maximum Wire Size
18 AWG
Mount Hole Center-to-Center Height
2 in

Details

Grounding
Grounded
NEMA Plug Configuration
L5-15P
Shrouded
No
Polarized
Yes
Cover Type
No Cover
Number of Blades
3
Connection Orientation
Straight
Number of Outlets
1
UL 94 Flammability Rating
V-2
Horsepower Rating
1/2 hp
Voltage Rating
125V AC
Number of Poles
2
Phase
Single
Resistance Properties
Impact Resistant
Current Rating
15 A
Flange Shape
Round
Mount Type
Surface
Item
Locking Inlet
Flange Material
Thermoplastic
Housing Material Finish
Brass
Standards
UL 498
Maximum Operating Temperature
115 Degrees C
Minimum Operating Temperature
-40 Degrees C
Flange Type
Flanged
Number of Gangs
1
Features
Corrosion Resistant
Grade
General Use
Series
TURNLOK(R)
Midget Locking
No
Housing Color
Gray

Description

Locking Inlet, Cover Type No Cover, Current Rating 15 A, Flange Material Thermoplastic, Flange Shape Round, Housing Color Gray, IP Rating Not Applicable, Mount Type Surface, NEMA Enclosure Rating Not Applicable, NEMA Plug Configuration L5-15P, Number of Blades 3, Number of Poles 2, Phase Single, Resistance Properties Impact Resistant, Voltage Rating 125V AC, Wiring Style Standard, Flange Diameter 2.56 in, Flange Height Not Applicable, Flange Type Flanged, Flange Width Not Applicable
