Shop LEVITON

Duplex Straight Blade Receptacle, 6-20R, 20 A, 250V AC, 2 Pole, 3 Wire, Flush Mount, Grounded

  • Mfr # 5461-CR

  • Zoro # G216090076

product price:  $32.29
/ea

Key Features

Receptacle Type
Single
NEMA Receptacle Configuration
6-20R
Current Rating
20 A
Voltage Rating
250V AC
Phase
Single
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
5461-CR
Zoro #
G216090076
UPC #
078477106600
Country of Origin
Mexico

Dimensions

Minimum Wire Size
18 AWG
Maximum Wire Size
10 AWG
Mount Hole Center-to-Center Height
3.3 in

Details

Item
Duplex Straight Blade Receptacle
Receptacle Type
Single
NEMA Receptacle Configuration
6-20R
Current Rating
20 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Side
Grounding
Grounded
Housing Color
Yellow
Mount Type
Flush
Standards
ANSI-C-73, CSA C22.2 No. 42 File LR-406, NEMA WD-6, UL 498, UL FED SPEC WC-596 File E13399
Resistance Properties
Corrosion Resistant
Number of Gangs
1
Contact Material
Nickel-Plated Brass
UL 94 Flammability Rating
V-2
Maximum Operating Temperature
60 Degrees C
Market
Industrial
Minimum Operating Temperature
-40 Degrees C
Features
Smooth Face
For Environment
Food and Beverage, Oily/Greasy
Connection Orientation
Straight
Number of Outlets
1
Housing Material
Santoprene TPV
Cover Type
No Cover
NEMA Enclosure Rating
Not Rated
GFCI
No
Horsepower Rating
2 hp
Polarized
Yes
Shrouded
No
Flange Type
Non-Flanged
Number of Wall Plates Included
0
Grade
Federal Specification
IP Rating
Not Rated
Surge Protection
No
AFCI
No

Description

Duplex Receptacle Outlet
