Flanged Locking Receptacle, L15-20R, 20 A, 250V AC, Three Phase, 3 Pole, Flush Mount, Yellow

  • Mfr # 24CM-20
  • Zoro # G716090422

product price:
$
61.95
/ea

Key Features

NEMA Receptacle Configuration
L15-20R
Current Rating
20 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
3
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
24CM-20
Zoro #
G716090422
UPC #
-
Country of Origin
Mexico
Item
Flanged Locking Receptacle
NEMA Receptacle Configuration
L15-20R
Current Rating
20 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
3
Number of Wires
4
Wire Connection Type
Screw Terminals
Grounding
Grounded
Housing Color
Yellow
Mount Type
Flush
Flange Type
Non-Flanged
Standards
ANSI C-73, CSA C22.2 No. 42, NEMA WD-1 and WD-6, NOM 57, UL 498, UL FED SPEC W-C-596
Resistance Properties
Corrosion Resistant
Wiring Style
Standard
Shrouded
Yes
NEMA Enclosure Rating
Not Rated
Maximum Operating Temperature
60 Degrees C
Number of Gangs
1
Minimum Operating Temperature
-40 Degrees C
Contact Material
Nickel-Plated Brass
For Environment
Corrosive
Housing Material
Valox
Market
Industrial
Polarized
Yes
Connection Orientation
Straight
Horsepower Rating
1 hp
UL 94 Flammability Rating
V-0
IP Rating
Not Rated
Hub Type
Dead End
Number of Outlets
1
Series
Insulgrip
Midget Locking
No
Cover Type
No Cover

Dimensions

Minimum Wire Size
14 AWG
Face Plate Height
2.67 in
Face Plate Width
1.69 in
Face Diameter
1.56 in
Maximum Wire Size
8 AWG
Overall Depth
1.31 in
Mount Hole Center-to-Center Height
3.75 in

Description

Flush Mtg Locking Receptacle,Yellow
