- MFR #
- GFNT2-I
- Zoro #
- G004392870
- UPC #
- 07847771277
- Country of Origin
- China
- Item
- GFI Receptacle
- Cover Type
- No Cover
- Current Rating
- 20 A
- Phase
- Single
- GFCI
- Yes
- Grounding
- Grounded
- Number of Outlets
- 2
- Housing Color
- Ivory
- Housing Material
- Polycarbonate
- NEMA Receptacle Configuration
- 5-20R
- Number of Poles
- 2
- Number of Wires
- 3
- Polarized
- Yes
- Standards
- CSA C22.2 - 144.1 (GFCI) and 42 (Receptacles), CSA Certified, CSA Certified LR-57811, NOM Certified, UL 943 Class A (GFCI) and 498 (Receptacles), UL Listed, UL Listed E48380
- HP
- 1 hp
- Amps - Plugs and Receptacles
- 20 A
- Mounting Type - Plugs and Receptacles
- Flush
- Color
- Ivory
- Tamper Resistant
- No
- Voltage - Plugs and Receptacles
- 125V
- Wiring Method - Plugs and Receptacles
- Back and Side
- Voltage
- 125 VAC
- Type
- Standard Duplex
- Surge Suppression
- Yes
- Color - Plugs and Receptacles
- Ivory
- Item - Plugs and Receptacles
- GFCI Receptacle
- Outlet Type - Plugs and Receptacles
- Standard Duplex
- NEMA Receptacle Configuration - Plugs and Receptacles
- 5-20R
- Application Environment
- Commercial
- Power Indicator
- Yes
- Special Features
- Auto Adapts and Shifts, Auto-Monitoring, Continuous Ground Fault Protection, Over-Voltage Resistant, Patented Lockout Action Prevents Reset, Standard Brass Self-Grounding Clip
- Weather Resistant - Plugs and Receptacles
- No
- Wiring Method
- Back/Side
- Self-Testing
- Yes
- Includes
- Faceplate, Wallplate
- Mount Type
- Flush
- Minimum Operating Temperature
- -31 Degrees F
- Surge Protection
- No
- Grade
- Federal Specification
- Contact Material
- Brass
- Wire Connection Type
- Screw Terminals
- Receptacle Type
- Decorator Duplex
- Voltage Rating
- 125V AC
- Market
- Commercial, Residential
- Includes Mounting Hardware
- Yes
- Horsepower Rating
- 1 hp
- Maximum Operating Temperature
- 150.8 Degrees F
- Visual Indicator Lights
- Power Connected
- Self Testing
- Yes
- CSA C22.2 No. 42
- Yes
- Feature
- Self-Test
- At Rated Voltage
- 1 HP
- UL498
- Yes
- NEMA
- 5-20R
- Strap Material
- Galvanized Steel
- Pole
- 2
- Dielectric Voltage
- Withstands 1250VAC per UL 943 and CSA-C22.2 No. 144.1-06
- Fed Spec WC-596
- Yes
- ANSI
- C-73
- Line Contacts
- Brass Double Wipe .031 Thick
- Terminal Screws
- Plated Steel
- Operating Temperature
- -35C to +66C
- Face Material
- Thermoplastic
- Wallplate
- Included
- Torque Range
- 14-18 in.-lbs
- Amperage
- 20 A
- Yoke
- Zinc-Plated Steel
- Trip Level
- Class A, 5mA plus or minus 1mA
- CSA-C22.2 No. 144.1-06
- File LR-57811
- Temperature Rise
- Max 30C after 100 cycles OL at 150 percent rated current
- Standards and Certifications
- UL/CSA, NEMA WD6
- Grounding Screw
- Plated Steel
- Terminal Accom.
- 14-10 AWG
- Body Material
- Polycarbonate
- Terminal ID
- Brass-Hot, Green-Ground, Silver-Neutral
- Termination
- Back & Side
- Clamps
- Brass
- Wire
- 3
- Short Circuit Current Rating
- 10KA
- Status Indicator Lights
- Power Connected
- IP Rating
- Not Rated
- Number of Wall Plates Included
- 1
- AFCI
- No
- Shrouded
- No
- Number of Gangs
- 1
- Flange Type
- Non-Flanged
- NEMA Enclosure Rating
- Not Rated
