Plugs and Receptacles
- Mfr # 16R22-UG
- Zoro # G722586315
product price:Â
$
57.39
/ea
Key Features
Mounting Style
Through Hole Mounting
Voltage Rating
600V AC, 600V DC
Housing Material
Santoprene TPV
Overall Width
2.28 in
NEMA Enclosure Rating
3R
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 16R22-UG
- Zoro #
- G722586315
- UPC #
- 78477716809
- Country of Origin
- Mexico
- Mounting Style
- Through Hole Mounting
- Voltage Rating
- 600V AC, 600V DC
- Housing Material
- Santoprene TPV
- Item
- Single Pole Receptacle
- NEMA Enclosure Rating
- 3R
- End Type
- Taper Nose
- Current Rating
- 400 A
- Terminal Connection Type
- Double Set Screw
- Connection Orientation
- Angled
- Housing Color
- Green
- Minimum Operating Temperature
- -40 Degrees F
- Resistance Properties
- Chemical Resistant, UV/Sunlight Resistant
- Gender
- Female
- Maximum Operating Temperature
- 185 Degrees F
- Series
- 16
- Standards
- UL/CSA 1691
- Contact Material
- Brass
- Flange Shape
- Square
- For Location
- Outdoor
Description
Single Pole Receptacle, Connection Orientation Angled, Current Rating 400 A, Gender Female, Housing Color Green, Housing Material Santoprene TPV, Maximum Wire Size 4/0 AWG, Minimum Wire Size 2/0 AWG, Voltage Rating 600V AC, 600V DC, Contact Material Brass, End Type Taper Nose, Flange Height 2.28 in, Flange Shape Square, Flange Width 2.28 in, NEMA Enclosure Rating 3R, Standards UL/CSA 1691, Terminal Connection Type Double Set Screw, For Location Outdoor
