Shop LEVITON

PlugsandReceptacles, 20A, 125VAC, Wht, Nylon

  • Mfr # 16362-PLW

  • Zoro # G122586588

product price:
$
52.19
/ea

Key Features

Wiring Method
Back/Side
Grounding
Grounded
For Environment
Food and Beverage, Oily/Greasy
Flange Type
Non-Flanged
Phase
Single
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
16362-PLW
Zoro #
G122586588
UPC #
78477109120
Country of Origin
Mexico

Dimensions

Overall Depth
1.1 in
Face Plate Height
2.6 in
Mount Hole Center-to-Center Height
3.3 in
Face Plate Width
1.3 in

Details

Wiring Method
Back/Side
Grounding
Grounded
For Environment
Food and Beverage, Oily/Greasy
Flange Type
Non-Flanged
Phase
Single
Horsepower Rating
1 hp
Number of Wires
3
Current Rating
20 A
Polarized
Yes
Number of Poles
2
NEMA Receptacle Configuration
5-20R
Item
Plugs and Receptacles
NEMA Enclosure Rating
Not Rated
Surge Protection
No
Number of Outlets
2
Housing Material
Nylon
Connection Orientation
Straight
Number of Gangs
1
AFCI
No
GFCI
No
Cover Type
No Cover
Market
Commercial
Grade
Hospital Grade
Wire Connection Type
Screw Terminals
Mount Type
Flush
Features
Smooth Face
IP Rating
Not Rated
Standards
CSA, FULS Marking, UL
Receptacle Type
Duplex
Shrouded
No
Housing Color
White
Number of Wall Plates Included
0
Voltage Rating
125V AC

Description

Plugs and Receptacles, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color White, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Not Applicable, Standards CSA, FULS Marking, UL
