Single Receptacle/Outlet, 20A, Ivory, 125V
- Mfr # 5362-2PI
- Zoro # G122982182
product price:Â
$
28.89
/ea
Key Features
Face Plate Height
2.6 in
Wiring Method
Back/Side
Face Plate Width
1.3 in
Features
Smooth Face
Minimum Operating Temperature
-40 Degrees C
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 5362-2PI
- Zoro #
- G122982182
- UPC #
- 078477704967
- Country of Origin
- Mexico
- Wiring Method
- Back/Side
- Features
- Smooth Face
- Minimum Operating Temperature
- -40 Degrees C
- Number of Wires
- 3
- Resistance Properties
- Tamper Resistant
- Receptacle Type
- Duplex
- NEMA Receptacle Configuration
- 5-20R
- Housing Color
- Ivory
- Standards
- CSA, FULS Marking, UL
- Current Rating
- 20 A
- Number of Poles
- 2
- Connection Orientation
- Straight
- For Environment
- Food and Beverage, Oily/Greasy
- Grounding
- Grounded
- Maximum Operating Temperature
- 75 Degrees C
- Horsepower Rating
- 1 hp
- Voltage Rating
- 125V AC
- Market
- Industrial
- Housing Material
- Nylon
- Item
- Single Receptacle/Outlet
- Wire Connection Type
- Screw Terminals
- Number of Outlets
- 2
- Contact Material
- Brass
- UL 94 Flammability Rating
- V-2
Dimensions
- Face Plate Height
- 2.6 in
- Face Plate Width
- 1.3 in
- Overall Depth
- 1.3 in
- Maximum Wire Size
- 10 AWG
- Minimum Wire Size
- 14 AWG
- Mount Hole Center-to-Center Height
- 3.3 in
- Fits Chest Size
- Smooth Face
Description
Single Receptacle/Outlet, Connection Orientation Straight, Current Rating 20 A, Grounding Grounded, Housing Color Ivory, Housing Material Nylon, NEMA Receptacle Configuration 5-20R, Number of Poles 2, Number of Wires 3, Receptacle Type Duplex, Resistance Properties Tamper Resistant, Standards CSA, FULS Marking, UL, Voltage Rating 125V AC, Wire Connection Type Screw Terminals, Wiring Method Back/Side, Horsepower Rating 1 hp, UL 94 Flammability Rating V-2
