Leviton Straight Blade Plug, 15 A, 125V AC, 2 Pole, Screw Terminals, Grounded 08219-PLC - main

Straight Blade Plug, 15 A, 125V AC, 2 Pole, Screw Terminals, Grounded

  • Mfr # 08219-PLC

  • Zoro # G4575100

product price:  $25.49
/ea

Key Features

NEMA Plug Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Number of Poles
2
Wire Connection Type
Screw Terminals
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
08219-PLC
Zoro #
G4575100
UPC #
78477960363
Country of Origin
United States

Dimensions

Cord Size
.245 - .700

Details

Item
Straight Blade Plug
NEMA Plug Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Number of Poles
2
Wire Connection Type
Screw Terminals
Connection Orientation
Straight
Grounding
Grounded
Housing Color
Clear
Standards
C-73, File E13400
Resistance Properties
Chemical Resistant, Corrosion Resistant, Impact Resistant
Special Features
Ratings and NEMA I.D. permanently marked on device; Certified for current interrupting at full rated current
Material
Nylon; Thermoplastic
Grade
Hospital
Number of Wires
3
Terminal ID
Brass-Hot, Green-Ground, White-Neutral
Terminal Screws
Brass
Cord-Clamp
Nylon
Body Material
Super Tough Nylon
Operating Temp.
-40°C to 60°C
Wire Gauge
18-10 AWG
Environment
Dry
Blade Material
Solid Brass
Assembly Screws
Steel, Zinc Plated
Flammability
Rated V-2 per UL 94
Dielectric Strength
Withstands 2000V per UL498
Temp. Rise
Max 30C after 250 cycles OL at 200 percent rated current
Clamp Insert
Nylon

Description

The Leviton line of Straight Blade Plugs and Connectors includes: Black & White Industrial Grade devices that resist impact, corrosion and chemicals; Wetguard for water or moisture resistance; Dustgard for dust and dirt; Python, with an innovative interlocking design; rugged nylon flanged and outlets; and integrated inlets and outlets with weather resistant covers.


  • • 8-32 brass wiring screws and formed plated steel wiring nuts
  • • Clear Lexan back cover
  • • Clear husk
  • • Straight blade connector
  • • Natural nylon body
  • • Nylon cable clamp with removable insert
