Straight Blade Plug, 5-20P, 20 A, 125V AC, 2 Pole, Screw Terminals, Grounded
Mfr # 8356-V
Zoro # G0812771
product price: $14.59
/eaKey Features
NEMA Plug Configuration
5-20P
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
8356-V
Zoro #
G0812771
UPC #
-
Country of Origin
Mexico
Dimensions
For Maximum Cable Diameter
0.70 in
For Minimum Cable Diameter
0.245 in
Maximum Wire Size
10 AWG
Body Length
1.81 in
Minimum Wire Size
18 AWG
Description
Python Plug, Connection Orientation Straight, Current Rating 20 A, Grounding Grounded, Horsepower Rating Not Applicable, Housing Color White, IP Rating Not Rated, NEMA Plug Configuration 5-20P, Number of Blades 3, Number of Poles 2, Phase Single, Polarized Yes, Resistance Properties Impact Resistant, UL 94 Flammability Rating V-2, Voltage Rating 125V AC, Wire Connection Type Screw Terminals, Wiring Style Hinged, Face Diameter Not Applicable, For Maximum Cable Diameter 0.7 in
