  6. Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Self-Grounded
Leviton Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Self-Grounded AFTR1-T - main

Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Self-Grounded

  • Mfr # AFTR1-T

  • Zoro # G704256052

product price:  $33.99
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
AFTR1-T
Zoro #
G704256052
UPC #
07847757490
Country of Origin
China

Dimensions

Maximum Wire Size
10 AWG
Minimum Wire Size
14 AWG

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Self-Grounded
Housing Color
Light Almond
Mount Type
Flush
Standards
ANSI C73, CSA C22.2 No. 42, NOM 057, UL 498, UL Federal Specification WC-596, UL1699.A
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Application Environment
General Purpose
Self-Testing
No
Surge Suppression
Yes
HP
1 hp
Wiring Method - Plugs and Receptacles
Back and Side
Special Features
Device Design Reduces Nuisance Tripping, Impact-Resistant, Over-Voltage Resistant, Silver Alloy Contact, Two-Year Product Warranty
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Outlet Type - Plugs and Receptacles
Blank Face
Tamper Resistant
Yes
Weather Resistant - Plugs and Receptacles
No
Power Indicator
Yes
Horsepower Rating
1 hp
Minimum Operating Temperature
-31 Degrees F
Self Testing
No
Polarized
Yes
Reset Type
Automatic
Connection Orientation
Straight
Contact Material
Brass
Maximum Operating Temperature
150.8 Degrees F
Wall Plate Material
Nylon
Grade
General Use
UL 94 Flammability Rating
V-2
Surge Protection
No
Visual Indicator Lights
Power Connected
Reverse Service
Yes
Includes
Screws, Self Grounding Clip
Hub Type
Feed Through
GFCI
No
AFCI
Yes
Compatible with Series
AFTR1
Housing Material
Polycarbonate
Cover Type
No Cover
Number of Outlets
2
Strap Material
Galvanized Steel
Line Contacts
Brass Double-Wipe .031 Thick
Feature
Tamper-Resistant
Operating Temperature
-35C to +66C
UL498
Yes
CSA Technical Information Letter No. M-02A
Yes
Yoke
Zinc-Plated Steel
Wire
3
CSA C22.2 No. 42
Yes
Flammability
Rated V-2 per UL 94
Face Material
Thermoplastic
Terminal Accom.
14-10 AWG
Termination
Back & Side
Body Material
Polycarbonate
Pole
2
Torque Range
14 -18 in.-lbs
Wallplate
Included
UL1699.A
File E342815
Standards and Certifications
UL/CSA, NEMA WD6
Series
AFTR1
ANSI
C-73
Grounding Screw
Plated Steel
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
At Rated Voltage
1 HP
Clamps
Brass
Dielectric Voltage
Withstands 1250VAC per UL 1699A
Terminal Screws
Plated Steel
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 15 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Light Almond, Housing Material Polycarbonate, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-15R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Decorator Duplex, Resistance Properties Tamper Resistant
