  11. Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Brown
Leviton Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Brown TCR15 - main

Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Brown

  • Mfr # TCR15

  • Zoro # G404393231

product price: $5.29
/ea
Sold in multiples of 10 for $52.90

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TCR15
Zoro #
G404393231
UPC #
07847765530
Country of Origin
Mexico

Dimensions

Minimum Wire Size
14 AWG
Maximum Wire Size
10 AWG
Face Plate Height
2.8 in
Overall Depth
1 in
Mount Hole Center-to-Center Height
3.3 in
Face Plate Width
1.3 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Side
Grounding
Self-Grounded
Housing Color
Brown
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, NEMA WD-1 & WD-6, NOM 057, cULus
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Sub-Category
Duplex Receptacles
Wiring Method - Plugs and Receptacles
Side
Application Environment
Commercial
Tamper Resistant
Yes
HP
1/2 hp
Outlet Type - Plugs and Receptacles
Duplex
Material
Thermoplastic (Body and Face)
Minimum Operating Temperature
-40 Degrees F
NEMA Enclosure Rating
Not Rated
Horsepower Rating
1/2 hp
Number of Outlets
2
Grade
Federal Specification
Housing Material
Thermoplastic
Polarized
Yes
Cover Type
No Cover
Market
Commercial
Maximum Operating Temperature
140 Degrees F
Contact Material
Brass
Connection Orientation
Straight
Includes Mounting Hardware
Yes
GFCI
No
Dielectric Voltage
Withstands 2000V per UL498
Feature 2
Tamper-Resistant
Wire Type
Solid or Stranded Building Wire
Wire
3
Temperature Rise
Max 30C after 100 cycles OL at 150 percent rated current
Body Material
Thermoplastic
Device Type
Duplex Receptacle Outlet
Ground Clips
Brass
Screw Terminal Torque
14-18 in-lbs
Pole
2
Terminal Accom.
10-14 AWG
Flammability
Rated V-2 per UL94
Operating Temperature
-40°C to 60°C
ANSI
C-73
Feature 4
Smooth Face
Current Limiting
Full Rated Current
Termination
Side Wire
Strap Material
Zinc-Plated Steel
cULus
File E13399
Shutter Mechanism
Delrin® Acetal
Terminal Screws
Plated Steel
Grounding Screw
Plated Steel
Face Material
Thermoplastic
Line Contacts
Brass .031 Thick
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 15 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Brown, Housing Material Thermoplastic, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-15R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Tamper Resistant
