  6. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Light Almond
Leviton Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Light Almond AFTR2-T - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Light Almond

  • Mfr # AFTR2-T

  • Zoro # G804393350

product price:  $38.85
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
AFTR2-T
Zoro #
G804393350
UPC #
07847757501
Country of Origin
China

Dimensions

Maximum Wire Size
10 AWG
Minimum Wire Size
14 AWG

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Self-Grounded
Housing Color
Light Almond
Mount Type
Flush
Standards
ANSI C73, CSA C22.2 No. 42, NOM 057, UL 498, UL Federal Specification WC-596, UL1699.A
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Tamper Resistant
Yes
Surge Suppression
Yes
Application Environment
General Purpose
Power Indicator
Yes
Includes
Screws, Self Grounding Clip
Wiring Method - Plugs and Receptacles
Back and Side
Outlet Type - Plugs and Receptacles
Blank Face
HP
1 hp
Special Features
Device Design Reduces Nuisance Tripping, Impact-Resistant, Over-Voltage Resistant, Silver Alloy Contact, Two-Year Product Warranty
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Weather Resistant - Plugs and Receptacles
No
Self-Testing
No
Minimum Operating Temperature
-31 Degrees F
Cover Type
No Cover
Reset Type
Automatic
Number of Outlets
2
UL 94 Flammability Rating
V-2
Housing Material
Polycarbonate
Wall Plate Material
Nylon
Connection Orientation
Straight
Surge Protection
No
AFCI
Yes
Polarized
Yes
Maximum Operating Temperature
150.8 Degrees F
Grade
General Use
Contact Material
Brass
Reverse Service
Yes
GFCI
No
Visual Indicator Lights
Power Connected
Hub Type
Feed Through
Horsepower Rating
1 hp
Compatible with Series
AFTR2
Self Testing
No
CSA C22.2 No. 42
Yes
Grounding Screw
Plated Steel
CSA Technical Information Letter No. M-02A
Yes
Feature
Tamper-Resistant
UL 498
Yes
Termination
Back & Side
ANSI
C-73
At Rated Voltage
1 HP
Line Contacts
Brass Triple-Wipe
Flammability
Rated V-2 per UL 94
Face Material
Thermoplastic
Wire
3
Terminal Screws
Plated Steel
Dielectric Voltage
Withstands 1250VAC per UL 1699A
Series
AFTR2
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
Torque Range
14 - 18 in.-lbs
Clamps
Brass
Standards and Certifications
UL/CSA, NEMA WD6
Pole
2
Strap Material
Galvanized Steel
Body Material
Polycarbonate
Operating Temperature
-35C to +66C
Wallplate
Included
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
UL1699.A
File E342815
UL Fed Spec WC-596
Yes
Terminal Accom.
14-10 AWG
Yoke
Zinc-Plated Steel

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Light Almond, Housing Material Polycarbonate, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Decorator Duplex, Resistance Properties Tamper Resistant
