  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, White
Leviton Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, White 8300-SGW - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, White

  • Mfr # 8300-SGW

  • Zoro # G304836470

product price: $18.99
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
8300-SGW
Zoro #
G304836470
UPC #
07847705719
Country of Origin
Mexico

Dimensions

Maximum Wire Size
10 AWG
Minimum Wire Size
14 AWG

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Self-Grounded
Housing Color
White
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42 File E152105, NOM 057, UL 498HG File E13399, UL Federal Specification WC-596 File E13399
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Tamper Resistant
Yes
Sub-Category
Duplex Receptacles
Application Environment
Extra Heavy-Duty Hospital Grade
Material
Nylon (Body and Face)
Outlet Type - Plugs and Receptacles
Duplex
HP
1 hp
Wiring Method - Plugs and Receptacles
Back and Side
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Polarized
Yes
GFCI
No
Horsepower Rating
1 hp
Maximum Operating Temperature
140 Degrees F
Grade
Hospital Grade Fed. Spec.
Number of Outlets
2
Connection Orientation
Straight
NEMA Enclosure Rating
Not Rated
Minimum Operating Temperature
-40 Degrees F
Cover Type
No Cover
UL 94 Flammability Rating
V-2
Housing Material
Nylon
Contact Material
Nickel-Plated Brass
Clamp Nuts
Nickel-Plated Brass
Screw Terminal Torque
14-18 in-lbs
Face Material
Nylon
Dielectric Voltage
Withstands 2000V per UL498
UL Fed Spec WC-596
File E13399
Yoke
Nickel-Plated Brass
Terminal ID
Brass-Hot, Green-Ground, White-Neutral
Current Limiting
Full Rated Current
Feature
Tamper-Resistant|Smooth Face
Grounding Screw
Nickel-Plated Brass 8-32
Operating Temperature
-40°C to 60°C
Terminal Screws
Nickel-Plated Brass 10-32
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
Terminal Accom.
14-10 AWG
CSA C22.2 No. 42
File 152105
Ground Clips
Nickel-Plated Brass
Termination
Back or Side Wire
Standards and Certifications
UL/CSA
Strap Material
Nickel Plated Brass
ANSI
C-73
Device Type
Duplex Receptacle Outlet
UL498HG
File E13399
Body Material
Nylon
Flammability
Rated V-2 per UL 94
Line Contacts
Nickel-Plated Brass Triple-Wipe .031 Thick

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color White, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Tamper Resistant
