Shop LEVITON

Toggle 4-Way, 20 Amp

  • Mfr # CS420-2W

  • Zoro # G422982264

product price:
$
22.15
/ea

Key Features

Overall Height
4.1 in
Strap Material
Steel
Voltage Rating
120/277V AC
Switch Depth
0.9 in
Number of Switches
1
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
CS420-2W
Zoro #
G422982264
UPC #
078477815885
Country of Origin
Mexico

Dimensions

Overall Height
4.1 in
Switch Depth
0.9 in
Minimum Wire Size
14 AWG
Overall Width
1.3 in
Switch Height
2.2 in
Maximum Wire Size
12 AWG

Details

Strap Material
Steel
Voltage Rating
120/277V AC
Number of Switches
1
Switch Type
4-Way
Standards
ANSI C-73, CSA C22 2 No. 111 File #152105, NEMA WD-1, NEMA WD-6, NOM 57, UL 20, UL FED SPEC WS896E File #E7458
Wiring Method
Side
Switch Function
Maintained
Grounding
Grounded
Wire Connection Type
Screw Terminals
Item
Toggle 4-Way, 20 Amp
Maximum Operating Temperature
65 Degrees C
Minimum Operating Temperature
-40 Degrees C
Color
White
Contact Material
Silver Alloy
Illuminated
No
Market
Commercial
Horsepower Rating
1 hp
Switch Material
Thermoplastic
Features
10-Year Limited, Withstands 1,500V for 1 minute
Housing Material
Thermoplastic
Current Rating
20 A

Description

Toggle 4-Way, 20 Amp, Color White, Current Rating 20 A, Illuminated No, Pilot Light No, Switch Function Maintained, Switch Type 4-Way, Voltage Rating 120/277V AC, Wiring Method Side, Horsepower Rating 1 hp, Maximum Wire Size 12 AWG, Minimum Wire Size 14 AWG, Number of Switches 1, Standards ANSI C-73, CSA C22 2 No. 111 File #152105, NEMA WD-1, NEMA WD-6, NOM 57, UL 20, UL FED SPEC WS896E File #E7458, Strap Material Steel, Switch Style Toggle, Wire Connection Type Screw Terminals
