Liquid-Tight Flex Metal Conduit, 3/4 in Trade Size, 100 ft, 4-1/4 in Bend, Steel, Blue

  • Mfr # LAFG-12

  • Zoro # G305670103

product price:  $297.99
/ea
Free Shipping & Returns

Key Features

Nominal Length
100 ft
Bend Radius
4-1/4 in
Material
Steel
Jacket Material
PVC
Finish
Galvanized
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
LAFG-12
Zoro #
G305670103
UPC #
-
Country of Origin
United States

Dimensions

Trade Size
3/4 in
Nominal Length
100 ft
Bend Radius
4-1/4 in
Inside Diameter
0.82 in, 0.84 in
Outside Diameter
1.05 in

Details

Item
Liquid-Tight Flex Metal Conduit
Material
Steel
Jacket Material
PVC
Finish
Galvanized
Jacket Color
Blue
Min. Operating Temp.
-22 Degrees F
Max. Operating Temp.
221 Degrees F
Series
LAFG
Jacketed
Yes
Approval Rating
ANSI, ANSI 169 Certified, ARRA, CEC, CE, CSA, FDA, NEC, NSF, RoHS, UL, UL-360, WEEE
Special Features
Direct Burial, Flame Retardant, Heavy-Duty, New Antimicrobial Jacket With Biocide Additive, Smooth Exterior
Usable Temperature Range
-30 Degrees C to 105 Degrees C Dry / 60 Degrees C Wet / 70 Degrees C Oil
Weight
40 lb
Resistance Properties
Mild Acid Resistant, Oil Resistant, Sodium Hypochlorite Resistant, UV Resistant
Wet Location
Yes
Standards
ANSI/UL-360, ARRA Certified, Canadian Electrical Code (CEC CSA 22.1-18), CE Declaration: BS EN IEC 61386 Classification Code 444240650414, CSA 22.1 18, CSA 22.1 J18, CSA Certified File No. LL18858, CSA Standard C22.2 No 56-17, FDA Approved CFR21, NEC (ANSI/NFPA-70) Article 350, NSF Certified 51/61, NSF/ANSI 169 Certified, RoHS Compliant, UL Listed File No. E29278, WEEE Compliant
Flexibility
Flexible
Color
Blue

Description

Liquid Tight Conduit, Trade Size 3/4 in, Bend Radius 4 1/4 in, Color Blue, Approval Rating ANSI, ANSI 169 Certified, ARRA, CEC, CE, CSA, FDA, NEC, NSF, RoHS, UL, UL-360, WEEE, Steel, Jacket Material PVC, Max. Operating Temp. 221 Degrees F, Min. Operating Temp. -22 Degrees F, Nominal Length 100 ft, Finish Galvanized, Flexibility Flexible, Inside Diameter 0.82 in, 0.84 in, Jacket Color Blue, Jacketed Yes, Outside Diameter 1.05 in
