Shop LIQUIDYNAMICS

Air Drum Pump, 4 gpm, 600 psi, 3:1

  • Mfr # TOB27R50ENQRAFR2
  • Zoro # G3782891
product price:
$
2,199.99
/ea
Free Shipping & Returns

Key Features

Ounces per Stroke
2.37 fl oz/stroke
Max. Output
4 gpm
Type
Air Operated
Capacity
330 gal
Spout Length (In.)
9 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
TOB27R50ENQRAFR2
Zoro #
G3782891
UPC #
-
Country of Origin
Italy

Dimensions

Spout Length (In.)
9 in
Container Size
330 gal
Air Motor Size (In.)
3 3/4 in
Outlet Size
1/2 in
Spout Length
9 in
Air Inlet Size
1/4 NPT
Air Outlet Size
1/2 in
For Container Size
275 gal
Hose Length
600 in
Air Inlet Connection Size
1/4 in
Hose Inside Diameter
1/2 in
Adapter Connection Diameter
2 in

Details

Item
Air Drum Pump
Ounces per Stroke
2.37 fl oz/stroke
Max. Output
4 gpm
Type
Air Operated
Capacity
330 gal
Fluid Outlet Thread (In.)
1/2 MNPT
Working Flow Max. (GPM)
4.6 gpm
Min. Air Inlet Pressure
50 psi
Fluid Inlet Thread (In.)
1 FNPT
Includes
Non-Preset Control Handle, Reel
For Use With
Gear Oil, Hydraulic Oil, JTTU Antifreeze and Similar Fluids, Pump Engine Oil, Transmission Fluid
Max. Air Inlet PSI
125 psi
Consumption @ 100 PSI
12 cfm
Fluid In/Out NPT (F)
1 in
Output
2.37 oz Per Stroke
Air Inlet (In.)
1/4 FNPT
Interval Time Between Cycles (Min.)
0.08 min
Pump Ratio
5:1
Outlet Pressure Max. (PSI)
600 psi
Pump for Multiple Outlets
Yes
Power Source
Air
Max. Oil Flow
2.37 g/stroke
Max. Outlet Pressure
600 psi
Max. Air Pressure
125 psi
Ratio
3:1
For Container Type
Tote
Air Consumption
12 cfm
Maximum Head Pressure
600 psi
Includes Follower Plate
No Follower Plate Included
Maximum Viscosity
14,000 cps
Variable Speed
No
Nozzle Material
Aluminum
Wetted Material
Aluminum/Nitrile/Steel
Hose Tube Material
Synthetic Rubber
Mounting Bracket Included
Tote Mounting Bracket
Minimum Air Pressure
120 psi
Discharge Connection Type
FNPT
Includes Bung Adapter
Yes
Maximum Flow Rate
4 gpm
Suction Tube Material
Steel
Pump Technology
Piston
Hazardous Location Class
Not Rated
Housing Material
Aluminum/Steel
Maximum Head
1,442 ft
Standards
CE
Includes Spout
Yes
For SAE Viscosity Grade - Maximum
140
Includes Nozzle
Yes
Discharge Tube Outlet OD
1/2 in
Air Inlet Connection Type
NPT
Chemical Compatibility
Engine Oil, Gear Lube, Hydraulic Oil
Static Protection
Not Groundable
Duty Cycle
Continuous
Includes Discharge Hose
Yes
Maximum Outlet Pressure
600 psi
Maximum Fluid Temperature
150 Degrees F
Pressure Ratio
3:1
Adapter Connection Standard
FNPT
Container Cover Type Included
No Cover Included
Housing Finish
Zinc Casted
Noise Level
90 dB
Includes Suction Tube
Yes
Nozzle Operation
Manual
Maximum Air Pressure
120 psi
Discharge Tube Outlet ID
1/2 in
Meter Type Included
Digital
Suction Tube OD
1 5/8 in
Maximum Oil Flow
2.37 g/stroke
Power Source - TS Only
Air
Power Source - old
Air

Description

Oil Pump Transfer System, Max. Air Pressure 125 psi, Spout Length 9 in, Air Outlet Size 1/2 in, Air Consumption 12 cfm, Hose Length 1/2 in
