Control Relay, Dual Pump Down, 120V

Mfr # LCP2D100
Zoro # G5962187

96.85

Key Features

Input Voltage

120V AC

Switch Type

Single Pole Double Throw

Enclosure Color

White

Enclosure Height (In.)

3 1/5 in

Type

Plug-In

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: LCP2D100
Zoro #: G5962187
UPC #: 801262084339
Country of Origin: United States

Dimensions

Enclosure Height (In.): 3 1/5 in
Enclosure Depth (In.): 2 4/5 in
Enclosure Width (In.): 1 7/10 in
Body Depth: 2.8 in
Body Width: 1.7 in
Body Height: 3.2 in

Details

Input Voltage: 120V AC
Switch Type: Single Pole Double Throw
Item: Level Control Relay
Enclosure Color: White
Type: Plug-In
Special Features: 10A Relay Output, 5V DC Pulsed Probe Voltage, Adjustable Sensitivity, LED Indication
Control Type: Liquid Level Dual Probe Pump Down
Application: Level Control Relay
Agency Compliance: cURus
Special Information: 8 Pin Octal Socket Required, Galvanically Isolated
Number of Probes: Dual Probe
Mounting Style: Socket
Standards: cURus
Maximum Resistance Sensitivity: 100,000 ohm
Relay Function: Pump Down
Minimum Resistance Sensitivity: 4,700 ohm
Electrical Connection: 8-Pin Terminal
Contact Form: SPDT
Base Shape: Octal
Features: 5V DC Pulsed Probe Voltage, Adjustable Sensitivity
Current Rating: 10 A
Status Indicator: LED Indicator
Number of Pins: 8
Contact Rating (AC): 10 A @ 240V AC
Contact Rating (DC): 7 A @ 28V DC

Description

Level Control Relay, Base Shape Octal, Contact Form SPDT, Current Rating 10 A, Electrical Connection 8-Pin Terminal, Flat Pin Width Not Applicable, Input Voltage 120V AC, Minimum Resistance Sensitivity 4,700 ohm, Maximum Resistance Sensitivity 100,000 ohm, Number of Pins 8, Number of Probes Dual Probe, Relay Function Pump Down, Contact Rating (AC) 10 A @ 240V AC, Contact Rating (DC) 7 A @ 28V DC, Mounting Style Socket, Status Indicator LED Indicator, Body Depth 2.8 in, Body Height 3.2 in
