Mersen IEC Switch, UL508, 25A, 3P M253 - main

IEC Switch, UL508, 25A, 3P

  • Mfr # M253

  • Zoro # G9041160

product price: $57.92
/ea

Key Features

Contact Form
3P
Current Rating
25 A
Phase
Three
Voltage
600 V
Standards
UL 508 Listed E196672; IEC 60947-3
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
M253
Zoro #
G9041160
UPC #
3605340557428
Country of Origin
Finland

Dimensions

Product Height
1.77 in
Product Length
2.13 in
Product Width
1.38 in

Details

Item
Safety Switch
Contact Form
3P
Current Rating
25 A
Phase
Three
Voltage
600 V
Standards
UL 508 Listed E196672; IEC 60947-3
Min Storage Temp
-25 °C
Max Operating Temp
40 °C
Short Circuit Rating Class Rk5
5 kA w/60A kA
Installation Mounting
Direct Screw Mount
Torque Rating
7 lb-in
Wire Connections
Box
Connection Terminal Type
Box
Short Circuit Rating Class J
10 kA w/60A kA
Number Of Poles
3-Pole
Rated Voltage Ac Ul
600 V
Rated Insulation Voltage
750 V
Short Circuit Current Rating Sccr
Up to 100 kA with fuses
Min Operating Temp
-5 °C
Max Storage Temp
55 °C
Rated voltage DC UL
0 V
Max Horsepower Rating/FLA
3-Phase: 240V 7.5HP, 480V 15HP, 600V 20HP; 1-Phase 120V 1.5HP, 240V 3HP
Short Circuit Current Rating (SCCR)
Up to 100 kA with fuses
Short Description
UL508 Non-Fused Disconnect 600V 25A 3 Pol
Short Circuit Rating (Class RK5)
5 kA w/60A kA
Short Circuit Rating (Class J)
10 kA w/60A kA

Description

IEC UL508 Switch 25A 3p
