2.54mm KK Hdr RA FricLK .5Au 3Ckt

  • Mfr # 22-12-4032

  • Zoro # G4051458

product price:
$
0.78
/ea
Sold in multiples of 148 for $115.44

Key Features

Max. Cycles at Max. Process Temperature
1
Orientation
Right Angle
Flammability
94V-0
UL
E29179
Termination Interface: Style
Through Hole
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
22-12-4032
Zoro #
G4051458
UPC #
-
Country of Origin
India

Dimensions

PCB Thickness - Recommended
1.60mm
PC Tail Length
3.80mm

Details

Max. Cycles at Max. Process Temperature
1
Orientation
Right Angle
Flammability
94V-0
UL
E29179
Termination Interface: Style
Through Hole
Circuits (Loaded)
3
Material - Metal
Brass
Durability (mating cycles max)
100
Material - Plating Termination
Tin
Material - Plating Mating
Gold
Current - Maximum per Contact
4.0A
Polarized to PCB
Yes
Plating min - Termination
0.508µm
Number of Rows
1
Pitch - Termination Interface
2.54mm
Process Temperature max. C
235
Voltage - Maximum
500V
Duration at Max. Process Temperature (seconds)
5
Material - Resin
Nylon
Color - Resin
Natural (White)
Shrouded
Partial
CSA
LR19980
Pitch - Mating Interface
2.54mm
Plating min - Mating
0.508µm
Lock to Mating Part
Yes
Circuits (maximum)
3
