  11. 6B SE M ins ScrwAg 6P 16A 500V
Molex 6B SE M ins ScrwAg 6P 16A 500V 936010215 - main

6B SE M ins ScrwAg 6P 16A 500V

  • Mfr # 936010215

  • Zoro # G2757821

product price: $16.45
/ea
Sold in multiples of 5 for $82.25

Key Features

Wire Protection
Yes
Poles
6
Number of Rows
2
Flammability
UL 94V-0
Material - Contact
Copper Alloy
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
936010215
Zoro #
G2757821
UPC #
-
Country of Origin
China

Dimensions

Stripping Length
7.00mm
Wire Size mm²
0.50-2.50
Wire Size AWG
14-20
Component Size
6B «44x27»

Details

Wire Protection
Yes
Poles
6
Number of Rows
2
Flammability
UL 94V-0
Material - Contact
Copper Alloy
Gender
Male
Tightening Test Torque
0.50 Nm
Voltage - Maximum
500V
Durability (mating cycles max)
700
Polarized to Mating Part
Yes
Temperature Range - Operating
-40° to +125°C
CSA
256883
Current - Maximum per Contact
16.0A
UL
E249674
Material - Insert
Polycarbonate
Insert Color
Grey
Material - Plating
Silver
Series
93601
Component Type
Inserts - Screw Terminal
Product Name
GWconnect
Insert Series
S-E
Standard
CSA C22.2 NO. 182.3, EN 60664-1, EN 61984, UL 1977
