  6. Board Connector, 50 Contact(S), 2 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Black
Molex Board Connector, 50 Contact(S), 2 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Black 901310145 - main

Board Connector, 50 Contact(S), 2 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Black

  • Mfr # 901310145

  • Zoro # G605891260

product price:  $3.15
/ea
Sold in multiples of 28 for $88.20

Key Features

Application
Signal, Wire-to-Board
Series
90131
Lock to Mating Part
None
Polarized to Mating Part
No
Pitch - Mating Interface
2.54mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
901310145
Zoro #
G605891260
UPC #
-
Country of Origin
Slovenia

Dimensions

PC Tail Length
2.90mm

Details

Application
Signal, Wire-to-Board
Series
90131
Lock to Mating Part
None
Polarized to Mating Part
No
Pitch - Mating Interface
2.54mm
Glow-Wire Capable
No
PCB Locator
No
Temperature Range - Operating
-55° to +125°C
CSA
LR19980
Number of Rows
2
Circuits (Loaded)
50
PCB Retention
None
Termination Interface Style
Through Hole
Current - Maximum per Contact
3.0A
Polarized to PCB
No
Breakaway
Yes
Keying to Mating Part
None
Voltage - Maximum
350V
First Mate / Last Break
No
Guide to Mating Part
No
Orientation
Vertical
Material - Resin
Polyester
Product Name
C-Grid III
Material - Plating Mating
Tin
Stackable
Yes
Material - Metal
Brass
Shrouded
No
Color - Resin
Black
Component Type
PCB Header
Material - Plating Termination
Tin

Description

Board Connector, 50 Contact(S), 2 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Black Insulator, Receptacle
