Wire Terminal, 14 AWG, 500 V, Grey
Mfr # 7316.6006.0
Zoro # G805980702
product price: $37.15
/eaSold in multiples of 3 for $111.45
Key Features
Insulation Color
Grey
Maximum Wire Size
14 AWG
Contact Material
Copper
Maximum Voltage
500 V
Minimum Operating Temperature
-40 Degrees C
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
7316.6006.0
Zoro #
G805980702
UPC #
-
Country of Origin
Italy
Dimensions
Maximum Wire Size
14 AWG
Stripping Length
7.00mm
Component Size
16B «77X27»
Details
Item
Wire Terminal
Insulation Color
Grey
Contact Material
Copper
Maximum Voltage
500 V
Minimum Operating Temperature
-40 Degrees C
Maximum Operating Temperature
125 Degrees C
Standards
CSA C22.2 NO. 182.3, EN 60664-1, EN 61984, UL 1977, UL E249674
Series
93601
Current - Maximum per Contact
16.0A
Component Type
Inserts - Screw Terminal
Number of Rows
2
Durability (mating cycles max)
700
CSA
256883
Material - Plating
Silver
Polarized to Mating Part
Yes
Material - Insert
Polycarbonate
Tightening Test Torque
0.50 Nm
Insert Series
S-E
Wire Protection
Yes
Poles
16
